TCL 2927 User Manual

Item No. Description Quantity Req. Designator Remarks
13-SFH615-A3P PHOTO COUPLER SFH615A3 1 IC802
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R813
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R833
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R807
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R834A
18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R805
18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R841
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R809
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R839
18-CB0303-JNX RES. C.F. 30K OHM 1/6W +/-5% 1 R808
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R806
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R837
18-CB0513-JNX RES. C.F. 51k OHM 1/6W +/-5% 1 R804
18-CD0102-JNX RES. C.F. 1k OHM 1/4W +/-5% 1 R811
18-CD0221-JNX RES. C.F. 220 OHM 1/4W +/-5% 1 R838
18-CD0470-JNX RES. C.F. 47 OHM 1/4W +/-5% 1 R810
18-CE0332-JNX RES. C.F. 3.3k OHM 1/2W +/-5% 1 R843
18-FE0124-JNX RES. M.O. 120K OHM 1/2W +/-5% 1 R840
18-FG0104-JHX RES. M.O. 100K OHM 2W +/-5% 1 R851
18-FG0104-JHX RES. M.O. 100K OHM 2W +/-5% 1 R852
18-FG0221-JHX RES. M.O. 220 OHM 2W +/-5% 1 R834
18-FG0330-JHX RES. M.O. 33 OHM 2W +/-5% 1 R832
18-FG0822-JHX RES. M.O. 8.2K OHM 2W +/-5% 1 R842
18-FH0223-JLX RES. M.O. 22K OHM 3W +/-5% 1 R831
18-KE0105-JN3 RES. H.VOLT. CC 1M OHM 1/2W +/-5% 1 R801
18-KE0105-JN3 RES. H.VOLT. CC 1M OHM 1/2W +/-5% 1 R802
18-KE0105-JN3 RES. H.VOLT. CC 1M OHM 1/2W +/-5% 1 R808B
18-KE0475-JNX RES. H. VOLT. CC 4.7M OHM 1/2W 1 R803
18-KF0825-JH3 RES. H.VOLT.CC 8.2M OHM 1W +/-5% 1 R835
20-TR102H-5CX TRIMMER B1K HORIZ TYPE 1 VR821
22-NTC479-XX0 NTC 4.7 OHM +/-18% NTC4.7D2-14 1 RT802
25-343260-M1X CAR. ELEC 1 C838
25-BCA102-M1X CAP. ELEC 1000 UF 16V +/-20% 1 C842
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C836A
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C845A
