TCL 2927 User Manual

Item No. Description Quantity Req. Designator Remarks
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R1022
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R1023
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R1004
18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R1007
18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R1005
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R1006
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1009
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1013
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1014
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1015
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1016
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C1019
25-BFB339-M1X CAP. ELEC 3.3 UF 50V +/-20% 1 C1010
26-ABC339-CZX CAP. CER 3.3 PF 50V +/-0.25 SL 1 C1001
26-ABC339-CZX CAP. CER 3.3 PF 50V +/-0.25 SL 1 C1002
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1031
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1034
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1037
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1038
26-EBP152-KBX CAP. CER 1500pF 50V +/-10% B 1 C1012
26-EBP220-JCX CAP. CER 22PF 50V +/-5% CH 1 C1035
26-EBP220-JCX CAP. CER 22PF 50V +/-5% CH 1 C1036
26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH 1 C1025
26-EBP560-JZX CAP. CER 56PF 50V +/-5% SL TUBE 1 C1004
26-EBP560-JZX CAP. CER 56PF 50V +/-5% SL TUBE 1 C1005
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C1006
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C1008
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C1011
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C1018
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C1023
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C1024
27-MBC474-J0X CAP. M.P.E 0.47UF 63V +/-5% 1 C1017
45-OSC18M-4Y0 CRYSTAL 18.432M 1 X1001
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 ‘+’TO Q918‘C’
‘-’TO Q919‘B’
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 R1011
‘+’TO IC1001 PIN4
