TCL 2927 User Manual

Item No. Description Quantity Req. Designator Remarks
13-MSP342-5GB IC MSP 3425G 1 IC1001
34-A220K0-1IX COIL PL - 22UH +/-10% LGA0305-220K 1 J1005
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J1001
41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J1004
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J1006
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J1009
41-WJ0080-B00 WIRE BARE JUMPER 8 MM 1 J1010
34-A220K0-1IX COIL PL - 22UH +/-10% LGA0305-220K 1 L1001
41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J1007
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J1008
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J1002
08-2918S6-YUY ASS'Y - YUV PARTS 1
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R242
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R243
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R914
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R915
47-RCA089-XX0 RCA SOCKET AV-3.2-3LK-N2 1 P904
08-2927S6-AG0 ASS'Y - AG PACKING PARTS 1
75-2927LL-CC0 POLYFOAM "LL" 0
75-2927LR-CC0 POLYFOAM (LR) 0
75-2927UL-CC0 POLYFOAM "UL" 0
75-2927UR-CC0 POLYFOAM "UR" 0
76-A2927U-0AT CARTON BOX 0
08-2927S6-CRY ASS'Y - CRT BD 1
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D501
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 L501 FOR "+" TO P1/P503
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D502
11-A562TM-0BX TRANSISTOR 2SA562TM-0 1 Q507
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q502
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q504
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q506
11-SC4544-0AX TRANSISTOR 2SC4544 1 Q501
11-SC4544-0AX TRANSISTOR 2SC4544 1 Q503
11-SC4544-0AX TRANSISTOR 2SC4544 1 Q505
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R515
31
