TCL 32S615 User Manual

12
Chapter 4 Using more of your TV
3.
Press
▲/▼
to select
Digital subtitle language 2nd
and press
OK/►
to enter.
4.
Press
▲/▼
to select a secondary subtitle language
and press
OK
toconrm.
5.
Press
EXIT
or to close the menu.
Shortcut operation:
Press
SUBT.
on the remote
control to directly select a subtitle language available for
the selected digital TV programme.
Selecting a Subtitle Type on Digital TV Channels
1.
Press on the remote control, select
Channel >
Subtitle > Subtitle type
and press
OK/►
to enter.
2.
Press▲/▼toselectasubtitletypeandpress
OK
to
conrm.Youcanselect
Hearing impaired
to display
the hearing impaired subtitles with your selected
language.
3.
Press
EXIT
or to close the menu.
Using Teletext
Selecting Decoding Page Language
1.
Press on the remote control, select
Channel >
Teletext > Decoding page language
and press
OK/►
to enter.
2.
Press
▲/▼
to select a proper type of language in
which Teletext will display and press
OK
toconrm.
3.
Press
EXIT
or to close the menu.
Digital Teletext Language
On digital TV channels, depending on the broadcaster,
you may be able to enjoy a service with multiple initial
Teletext pages in different languages. This function
allows you to select an available language as primary
language, which relates to different initial Teletext
pages.
1.
Press on the remote control, select
Channel >
Teletext > Digital teletext language
and press
OK/►
to enter.
2.
Press
▲/▼
to select a language and press
OK
to
conrm.
3.
Press
EXIT
or to close the menu.
Network Wake Up
This function allows you to turn on your TV from standby
mode via a network. To use this function, please make
sure:
1.
Your TV is connected to an effective home network;
2.
The desired controller, such as a smartphone, is
connected to the same network as your TV;
3.
An app which supports network waking up function,
has been installed into the controller;
4. Networked standby
is set to
On
in the
Network
& Internet
menu under homepage by pressing
>
(Settings)
>
General Settings
>
Network &
Internet
.
Installing Channels
This section describes how to search and store
channels automatically. This may be done in any of the
cases below:
-
you have skipped the channel installation step in the
initial setup;
-
you are prompted that there are no channels in TV
mode;
-
you want to update your channels.
1.
In TV mode, press on the remote control and
select
Channel
>
Channel scan
. Press
OK
/►to
enter.
2.
The TV installs and arranges channels according
toyourcountryorregion.Press▲/▼toselect
Country/Region
, and press
OK
/►toenter.Enter
the default password
1234
or your own password in
case you have changed the password in the
System
>
Lock
menu.Press▲/▼toselectyourcountryor
region and press
OK
to confirm.
3.
Press▲/▼toselect
Automatic search
and press
OK
/►toenter.
4.
Press▲/▼toselect
Channel type
andpress◄/►
to select
Digital
,
Analogue
or
Digital&Analogue
.
5.
Afterconfigurationiscompleted,press▼toselect
Search
and press
OK
to start scanning channels.
6.
The channel search may take a few minutes. After
the automatic search, channels are arranged in a
preset order. If you wish to hide or move channels,
press on the remote control, select
Channel
>
Channel organizer
and press
OK
/►toenter.
Using Subtitles
You can enable subtitles for each TV channel. Subtitles
are broadcast via Teletext or DVB-T digital broadcasts.
With digital broadcasts, you have the additional option
of selecting a preferred subtitle language.
Note:
Some options are available only when
Subtitle
is
set to
On
.
Turning On/Off Subtitles
1.
Press on the remote control, select
Channel >
Subtitle
and press
OK/►
to enter.
2.
Select the
Subtitle
option, press
OK/►
to enter,
press
▲/▼
to select
On
or
Off
and press
OK
to
conrm.
3.
Press
EXIT
or to close the menu.
Enabling Subtitle Languages on digital TV Channels
1.
Press on the remote control, select
Channel >
Subtitle > Digital subtitle language 1st
and press
OK/►
to enter.
2.
Press
▲/▼
to select a subtitle language as your
preferred language and press
OK
toconrm.

TCL 32S615 Specifications

General

Screen shape	Flat
Response time	30 ms
Display diagonal	32 \
Display brightness	210 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native refresh rate	60 Hz
Peak luminance ratio	77 %
LED backlighting type	Direct-LED
Viewable size diagonal	800 mm
Contrast ratio (typical)	-
Display diagonal (metric)	81.3 cm
Motion interpolation technology	PPI (Picture Performance Index) 300
Dynamic contrast ratio marketing name	Mega Contrast
Package depth	128 mm
Package width	830 mm
Package height	520 mm
Package weight	5100 g
Processor cores	4
Audio formats supported	MP3, WMA
Image formats supported	BMP, JPG, PNG
Video formats supported	AVI, H.264, H.265, MP4, MPG, OGM, TS, VP9, WMV
Picture processing technology	TCL Pure Image Ultra
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
Product color	Black
Mercury content	0 mg
Heavy metals free	Hg (mercury)
Panel mounting interface	100 x 100 mm
Audio decoders	Dolby Digital, Dolby Digital Plus
RMS rated power	10 W
Number of speakers	2
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth profiles	A2DP, HID
Number of OSD languages	29
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Video apps	Netflix
Smart modes	Game, Movie, Sports
Lifestyle apps	Google Apps
Operating system version	9.0
Operating system installed	Android
Hybrid Broadcast Broadband TV (HbbTV) version	1.5
HDMI version	1.4
RF connector type	F, IEC
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical out	1
Consumer Electronics Control (CEC)	SimpLink
Common interface Plus (CI+) version	1.3
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (max)	63 W
Power consumption (standby)	0.31 W
Power consumption (typical)	42 W
Remote control type	RC802N4
Certification	CE
Repairability index	6.4

Weight and Dimensions

Depth (with stand)	180 mm
Width (with stand)	720.6 mm
Height (with stand)	473.3 mm
Weight (with stand)	3550 g
Depth (without stand)	77.4 mm
Height (without stand)	424 mm
Weight (without stand)	3540 g
