Chapter 3 - Basic TV operations

Accessing channels

Using the numeric buttons

: press the corresponding

numeric buttons on the remote control to access the

channels.

Using the P / buttons

: press the

P /

buttons

on the remote control to scroll through the channels.

Using the LIST button

: press the

LIST

button on the

remote control to display the channel list and press

▲/▼/◄/►

and

to select channels.

Watching connected devices

Press on the remote control to display the source

list. Press

▲/▼

to select TV or other input sources

and press

to conrm.

You can also press on the remote control to

display the homepage, press ▲/▼/◄/► to move the

cursor to the area on the right top of the screen,

and press

to enter. Then press ▲/▼ and

select the input source.

Adjusting volume

Volume control

: press the

buttons on the

remote control to increase or decrease the volume.

Sound mute

: press the button to temporarily mute

the sound. Press this button again or the button

to restore the sound.

Accessing Android TV homepage

Allows you to enjoy Internet Applications (Apps) and

specially adapted Internet websites, and perform

system settings for your TV. You can make controlling

with the TV remote control.

WARNING:

• Congure the network settings before using Smart

TV applications.

• Slow responses and/or interruptions may occur,

depending on your network conditions.

• If you experience a problem using an application,

please contact the content provider.

• According to circumstances of the content provider,

an application’s updates or the application itself may

be discontinued.

• Depending on your country's regulations, some

applications may have limited service or not be

supported.

• Changes in application content may be made

without prior notice by the service provider.

Press on the remote control to display the

Android TV homepage.

Press

▲/▼/◄/►

and

to enter the desired

Apps, functions or settings.

Press to return to the homepage.

Note: Since the connection with Internet takes

time, it’s recommended that you wait a few

minutes to use the Smart TV feature after

activation of TV from standby.

Using TV settings menu

Allows you to adjust TV settings, such as picture and

sound.

Press

on the remote control to display the

Settings menu.

Press

▲/▼

to select the desired item, then press

OK/►

to enter the corresponding submenu.

In submenus, press

▲/▼

to select menu options,

then press

OK/►

to enter the option list, the

adjustment interface, or the corresponding

submenu.

Press to return to the previous menu.

Press

EXIT

or to close the menu.

Notes:

You can also press on the remote control,

select Settings (if available) and press OK to

enter the Settings menu. Some options may not

be available for certain signal sources.

Setting LED Motion clear on will make fast

moving images clearer by controlling the LED

backlight, but the picture will be darker and more

ickering than with LED Motion clear off.

Questions and Answers:

Need help?

Do you have a question about the TCL 40ES560 and is the answer not in the manual?

TCL 40ES560 Specifications

General

Screen shape	Flat
Response time	30 ms
Display diagonal	40 \
Display brightness	270 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	60 Hz
Peak luminance ratio	76 %
LED backlighting type	Direct-LED
Supported video modes	1080p
Viewable size diagonal	1000 mm
Contrast ratio (typical)	-
Display diagonal (metric)	101.6 cm
Motion interpolation technology	PPI (Picture Performance Index) 400
Dynamic contrast ratio marketing name	Mega Contrast
HDMI version	1.4
HDMI Quick Switch	Yes
RF connector type	F, IEC
USB 2.0 ports quantity	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.3
Processor cores	4
Audio formats supported	MP3, WMA
Image formats supported	BMP, JPG, PNG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, OGM, TS, VP9, WMV
Picture processing technology	TCL Pure Image Ultra
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
Video apps	Netflix
Smart modes	Game, Movie, Sports
Lifestyle apps	Google Apps
Operating system version	9.0
Operating system installed	Android
Hybrid Broadcast Broadband TV (HbbTV) version	1.5
Audio decoders	Dolby Digital, Dolby Digital Plus
RMS rated power	16 W
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth profiles	A2DP, HID
Product color	Black
Mercury content	0 mg
Heavy metals free	Hg (mercury)
Panel mounting interface	100 x 100 mm
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Remote control type	RC802N1
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (max)	75 W
Power consumption (standby)	0.29 W
Power consumption (typical)	46 W
Package depth	130 mm
Package width	1040 mm
Package height	634 mm
Package weight	8600 g
Certification	CE
Truck type	100 cbm
Pallet width	800 mm
Pallet height	1420 mm
Pallet length	1200 mm
Pallet weight	116660 g
Quantity per truck	792 pc(s)
Quantity per pallet	12 pc(s)
Number of pallets per truck	66 pc(s)
Maximum number of stacking cartons	4 pc(s)

Weight and Dimensions

Stand width	770 mm
Depth (with stand)	186 mm
Height (with stand)	575 mm
Depth (without stand)	75 mm
Width (without stand)	905 mm
Height (without stand)	524 mm
Weight (without stand)	6400 g
