TCL AT2127 User Manual

Item No. Description Quantity Req. Designator Remarks
11-C124ES-0BX TRANSISTOR PDTC124ES (NPN) 1 Q006
11-C124ES-0BX TRANSISTOR PDTC124ES (NPN) 1 Q902
11-C124ES-0BX TRANSISTOR PDTC124ES (NPN) 1 Q904
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q609
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q603
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q602
13-000040-53P IC 4053 (ANALOG SW) 1 IC901
13-000040-66P IC 4066 (ANALOG SW.) 1 IC902
13-A21V01-TOP MCU 8823KRNG(TCL-A21V01-TO) 1 IC201
14-LED05R-XX1 LED RED FB205 1 D051B
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R637
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R612A
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R613A
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R928
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R927
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R911
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R925
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R930
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R931
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R414
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R010
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R917
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R919
18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R020
18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R021
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R016
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R910
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R909
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R907
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R908
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R612
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R613
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R022
18-CB0432-JNX RES. C.F. 4.3K OHM 1/6W +/-5% 1 R023
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R018
