TCL AT2127 - Page 27

Item No. Description Quantity Req. Designator Remarks
18-CB0682-JNX RES. C.F. 6.8K OHM 1/6W +/-5% 1 R024
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R929
18-CE0479-JNX RES. C.F. 4.7 OHM 1/2W +/-5% 1 R918
18-EG0129-JHX RES. FUS. 1.2 OHM 2W +/-5% 1 R420
18-FF0122-JGX RES. M.O. 1.2k OHM 1W +/-5% 1 R411
18-FG0229-JHX RES. M.O. 2.2 OHM 2W +/-5% 1 R309
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C919
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C920
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C921
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C904
25-BCB220-M1X CAP. ELEC 22 UF 16V +/-20% 1 C015
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C009
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C918
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C926
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C928
26-AMK681-KBX CAP. CER 680 PF 2KV +/-10% B 1 C402
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C306
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C905
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C917
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C925
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C927
27-AGQ394-JSX CAP. M.PP 0.39UF 250VAC +/-5% 1 C421
27-ALR123-J0X CAP. M PP 0.012 UF 1.6KV +/-5% 1 C406B
36-LIN500-XX1 COIL LINEARITY 50 UH 1 L412
37-SC2502-78Q0X FBT BSC25-0278Q 1 T402
41-WJ0025-B00 WIRE BARE JUMPER 2.5mm 1 FOR Q903 (C - E)
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J025
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J201
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J906
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 JP001
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J905
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J023
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J603
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J912
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J916
27
