TCL D3000 Series User Manual

5
Introduction
Sockets and Connections
Notes
:
1)
The location and names of the sockets on the TV may vary according to TV model, and not all sockets available
on all models.
2) For some models, the USB 2.0 or HDMI 1 socket is service-compatible, which is marked as USB2.0/SERVICE or
HDMI 1/SERVICE. Please turn to qualied service personnel for debugging and maintenance.
USB 2.0 socket (input)
This socket can be used to connect a USB device.
HDMI 1/HDMI 2 socket (input)
TheHDMI(High-DenitionMultimediaInterface)socketletsyou
connect a device, such as a Blu-ray player, with a HDMI output
for best picture quality. It also provides an uncompressed digital
connection that carries both video and audio data by way of an
integrated mini-plug cable.
Note: For some models, the HDMI 2 socket is ARC-compatible.
ANTENNA/CABLE IN socket (input)
This socket can be used to connect the outside aerial.
SPDIF socket (output)
This socket can be used to connect a compatible digital audio
receiver.
AV RCA audio + video sockets (input)
The AV IN sockets can be used to connect a range of equipment,
including video recorders, camcorders, decoders, satellite receivers,
DVD players, or games consoles. The VIDEO IN socket provides
composite video connection.
Headphone socket (output)
This socket can be used to connect headphones or stereo
earphones.
Note
: When the Headphone socket is connected, the speakers will
be muted.
Warning
: Excessive sound pressure from earphones and
headphones can cause hearing loss.
SPDIF
or
AV IN
V L
R
L
VIDEO
R
V L R
USB 2.0
HDD
HDMI 1
HDMI 2
or
ANTENNA
/CABLE IN
