TCL LCD20W5HE User Manual

20" LCD TV TCL LCD20W5HE
61
044T3231508512 CHIELD D-SUB
U403 056T1133 77T2F EN29F040A-70JCP
U403 056T1133 80T2F A29040BL-70F PLCC-32
R898 061T152M479 64 4.7 OHM +-5% 2W
R720 061T152M479 64 4.7 OHM +-5% 2W
R712 061T152M479 64 4.7 OHM +-5% 2W
R714 061T152M759 64 7.5 OHM +-5% 2W
C606 067T215L102 3R LOW E.S.R 1000UF +-20% 16V
L712 073T 253137 LS CHOKE COIL
L702 073T 253137 LS CHOKE COIL
L606 073T 253158 L CHOKE COIL
L605 073T 253158 L CHOKE COIL
L604 073T 253158 L CHOKE COIL
L603 073T 253158 L CHOKE COIL
CN603 088T 30214K PHONE JACK
CN108 088T 35315F HA D-SU13 15PIN
090T 372 2 HEAT SINK
X401 093T 2253B J 14.31818MHZ/85C
X201 093T 2258B J 24.576MHZ/20PF/49US
X501 093T 2279B CRYSTAL 28.322MHZ 49U/S
X402 093T 2281B 10.000MHZ/30PF/49US
SMTFAF5BMTEQP MAIN BOARD AUTO INS
019T 553 8 SPRING
J101 033T802436C H HEADER FEMALE 36P 2.0MM
R146 061T153M100 59 10 OHM 5% 3W
R101 061T153M100 59 10 OHM 5% 3W
085T 583510 GASKET
J105 088T 78 10 2C RCA JACK
J104 088T 78 10 2C RCA JACK
J103 088T 78 1331N GP RCA JACK 1*3P R/B/G
JP100 088T 78 137CL AV-S-01-Y
J102 088T 35521A HC SCART CONN.R/A 21PIN
X601 093T 2268B J 18.432MHZ
TU101 094TPASEALL 3P FQ1216ME/IH-5(SV22)
SMTIOPFAA4P IO BOARD SMT FOR ROHS
CN1 033T3802 5H WAFER 5P RIGHT ANELE PI
J1 088T 30230C PHONE JACK
J1 088T 30230T PHONE JACK
GND 095T 900 53 HARNESS 95MM
SMTHJPFA60A8P TUNER BOARD SMT
CN2 033T3802 4 WAFER PH-4
U4 056T 627 5 TSOP4833
U4 056T 627 15 ECM-A33-N3 TSOP-48
095T 900 53 HARNESS 95MM
