12
If AC is Blocked by Storm Window Frame
Add wood as shown above or remove store window frame/obstruction before installing the
window air conditioner.
If the Storm Window Frame must remain, be sure the drain holes or slots are not caulked or
painted shut. Accumulated rainwater or condensation must be allowed to drain out.
Window Requirements
CAUTION
When opening the window, be sure that the fixed screws are secured
properly in place without any objects aecting their attachment to the
side brackets and associated window frame to prevent the unit from
becoming unstable and falling.
SASH
INSIDE
1-1/2”min
(38mm)
Storm window
frame or other
obstruction
Board thickness as
required, for proper
pitch to rear, along
entire sill.
Fasten with nails or
screws.
OUTSIDE
To Next Page
