TCL Air Conditioner Service Manual
5
Model No. TAC-24CS/K TAC-24CHS/K
Type Cooling Only Heating Pump
Control type Remote Remote
Rated cooling capacity Btu/h 24,000 24,000
Rated heating capacity Btu/h N/A 26,000
EER for cooling Btu/h.w 9.0 9.0
COP for heating W/W N/A 2.55
Moisture removal Liters/h 2.2 2.2
High dB(A) 47 47
Med. dB(A) 44 44
Indoor noise level at
cooling
Low dB(A) 40 40
Outdoor noise level dB(A) 58 58
Electrical Data
Power supply 220-240V~/50Hz
Voltage Range V
Cooling A 13 13
Rated current
Heating A N/A 13.8
Cooling W 2600 2600
Rated input
Heating W N/A 2800
Refrigerating System
Refrigerant/Charge Gram R22/2500g R22/2500g
Type Rotary Rotary
Model ------------------ -----------------
LRA A ------ -------
Compressor
MFG ----------------- -----------------
Evaporator Louver fin and Grooved tube type (φ7)
Condenser Corrugated fin and Grooved tube type (φ9.53)
Expansion device Capillary tube
Defrosting system Microcomputer controlled reverse system
Fan System
Indoor air circulation m
3
/h 1000 1000
Indoor fan type Cross flow Cross flow
Cooling rpm 1300/1200/1100 1300/1200/1100
Heating rpm N/A 1300/1200/1100
Dry rpm 1000 1000
Indoor fan speed
H/M/L
Sleep rpm 1000 1000
Indoor fan motor output W 35 35
Outdoor air circulation m
3
/h --- ---
Outdoor fan type Propeller fan Propeller fan
Outdoor fan speed rpm 850 850
Outdoor fan motor output W 110 110
Connections
Refrigerant coupling Flare type
Gas Inches 5/8 5/8
Connecting Pipe
Liquid Inches 3/8 3/8
Connecting Wiring
Size × Core
number
Drainage Pipe O.D 16mm
Others
Suitable area m
2
35~48 35~48
Indoor mm 1036×313×204 1036×313×204
Net dimensions
(W x H x D)
Outdoor mm 890×307×660 890×307×660
Indoor kg 16 16
Net weight
Outdoor kg 57 60
Indoor mm 1103×395×280 1103×395×280 Packing dimensions
(W x H x D)
Outdoor mm 990×405×705 990×405×705
Indoor kg 20 20
Gross weight
Outdoor kg 63 65
Loading Capacity 40’/40’HC 66/142/162 66/142/162
Note: The technical specifications is only reference.
