TCL TFF-60HRA

Air Conditioner Service Manual
14
Parts List
Indoor Unit- TFF-60HRA
No. Part No.
Part Name
Q’ty
Remark
1
210736221
Inside Base
1
2
230800121
Right Plate
1
3
230800122
Back Plate
1
4
230800120
Left Plate
1
5
211200107
Evaporator
1
6
230800124
Top Plate
1
7
210702134
Pipe Cover
1
8
230800123
Heat insulation board
1
9
1204090101
Rubber Water Drainage
1
10
210701012
Water Drainage
1
11
210800178
Inside Electrical Box
1
12
210901228A
Main PCB
1
13
1170200058
Terminal
1
14
230901276
Fan Motor Capacitor
1
15
1170240021
Transformer
1
16
1080520218
Inside Electrical Box Cover
1
17
210700120
Vertical Vane Connector
1
18
1170010008
Synchronization Motor
1
19
210800063
Synchronization Motor Cover
1
20
210736103
Out Blow Casing Foam
1
21
210736103
Step Motor
2
22
1071200014
Vertical Vane
1
23
210736100
Up-Left Ornamental Panel
1
24
210736098
Up Panel
1
25
210736101
Up-Right Ornamental Panel
1
26
210700116A
Horizontal Vane
1
27
210736102
Display PCB Supporter
1
28
210901229
Display PCB
1
29
210736099B
Display PCB Cover
1
30
210736105
Down-Left Ornamental Panel
1
31
210736104
Down panel
1
32
210736106
Down-Right Ornamental Panel
1
33
210826530
Air Filter Lead
2
34
210736108
Air Filter
1
35
1074090102
Lead Flow Circle
1
36
1070010004AA
Centrifugal Fan
1
37
1170030010
Indoor Motor
1
38
210700130
Volute Casing
1
39
1170230009
Indoor Sensor
1
Not shown in Explosion view
40
210900414A
Remote Controller
1
41
210708230
Remote Controller Supporter
1
42
1070110005
Drainage hose
1
43
211341339AD
Indoor Carton
1
