TCL TFF-60HRA

Air Conditioner Service Manual
16
Indoor Unit- TOF-60HSA
NO.
Part Number
Part Name
Q'ty
Remark
1
230800158
Left protection net
1
Optional
2
230900056
Outdoor fan motor
2
3
230800156
Cover
1
4
3210060247
Up condenser
1
3210060248
Down condenser
1
5
3120160027
Refrigerant tank
1
6
3072640201
Rear protection net
1
7
1170230005
Outdoor temp sensor
1
230901271A
Outdoor fan capacitor
2
3160080001
AC contactor
1
3171990066
Switch of low pressure
1
3171990210
Switch of high pressure
1
3172522102
Discharge temp sensor
1
3092520401AB
Outdoor PCB
1
8
1070350971
Handle
1
9
3210027077
Right back clapboard
1
10
3120120053
Three-way Valve
1
11
3210010257
Two-way Valve
1
12
3080028197
Partition plate
1
13
3120110018
4-way valve
1
3172510101
Winding of 4 way valve
1
3210010288
4-way valve assembly
1
14
3100070005
Compressor
1
15
3082510136
Outdoor base
1
16
3072510102
Front right clapboard
1
17
230700074
Outdoor Propeller Fan
2
18
230800157
Front board
1
19
1070251945
Air outlet griller
1
20
1191200310PX
Cabinet Carton
1
