TCL TS8132 Quick Start Guide

The LED display on the Sound Bar gives
you information about the status of the
Sound Bar.
11
Sound Bar LED Display
HELLO
*Power on/off
*Connect your Blu-ray player via
HDMI IN to use PASS THRU
*Input source
Reduced dynamics
Enhanced surround effect
Set preferred sound
Increase or decrease treble
or bass level
Volume
Mute/unmute
Previous, next music or pause
on USB mode
Set display brightness
Not support
Ready to work with AirPlay
Ready to work with Chromecast
Ready to work with Alexa
2s
Upgrade via OTA
Pair your subwoofer manually
Audio format detected
STDBY
STARTHELLO
HDMI 2 ARC
MUSIC
PAUSE
TV
USB
-X-
OPT HDMI 1 IN
MOVIE
NIGHT
V 28 V MAX V MIN
MUTE
airplay ready
cast ready
alexa ready
sub pair sub connected
DOLBY ATMOS DOLBY surround
SLEEP
SURR ON/OFF
tre -3 tre +3
BAS -3 BAS +3
update found
downloading
upg UPG OK
READY
PCM AUDIO
DIM 1 DIM 2
CONNECTEDBT PAIR
PASS THRoUgh
Remote Control LED Indications Remarks
HELLO
HELLO

TCL TS8132 Specifications

General

Truck type	87 cbm
Pallet width	1000 mm
Pallet height	2000 mm
Pallet length	1200 mm
Pallet net weight	252000 g
Quantity per truck	728 pc(s)
Quantity per pallet	28 pc(s)
Master (outer) case width	1090 mm
Master (outer) case height	355 mm
Number of pallets per truck	26 pc(s)
Master (outer) case net weight	9000 g
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	8720568100012
Package depth	275 mm
Package weight	Weight of the packaged product in gram.
Battery weight	15 g
Remote control battery type	AAA
Number of remote control batteries	2
Audio decoders	Dolby Atmos, Dolby Digital Plus, Dolby TrueHD
Equalizer modes	Movie, Music, TV
RMS rated power	350 W
Audio output channels	3.1.2 channels
Enhanced Audio Return Channel (eARC)	Yes
Bluetooth codec	A2DP, AVRCP
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Digital audio optical in	1
Subwoofer location	Separate
Subwoofer connectivity	Wireless
Woofer diameter (subwoofer)	5.25 \
Display type	LED
Product color	Black
Country of origin	China
Virtual assistant	Amazon Alexa & Google Assistant
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV
Operating temperature (T-T)	0 - 45 °C
Consumer Electronics Control (CEC)	T-link
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Cables included	AC, HDMI
Number of products included	2 pc(s)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Analog audio input	3.5
Sustainability certificates	CE

Weight and Dimensions

Depth	122 mm
Height	65 mm
Weight	6800 g
Soundbar weight	3300 g
Subwoofer width	200 mm
Subwoofer height	325 mm
Subwoofer weight	3500 g
