TCM FB15-7 - Lighting Components

9. ELECTRIC WIRING
- 153 -
A A
①
②
⑤
④
③
⑥
Section A - A
Fig. 9.4 Head Light
■ HEAD LIGHT
The head light has a structure as shown in Figure 9.4. Two head lights are installed on the front poles
of the overhead guard, one for each.
1. LENSE
2. RIM
3. HOUSING
4. REFLECTOR
5. GASKET
6. BULB
