Section IV: Parts List 1
D-2000 Closure, 16"–30"
Item Qty. Description
1 1 barrel collar
2 1 door
3 1 clamp ring
4 1 clamp ring handle
5 1 door hinge arm
6 1 clamp pivot plate
8 2 shaft collar
9 2 flat plain washer
10 2 handle link
11 3 grease fitting
12 2 bearing assembly
13 2 Clevis pin
14 2 spacer
15 1 O-ring
16 1 nameplate
17 1 pressure warning plate
18 1 pressure warning plate
19 2 clamp ring locking lug
20 1 Spirol™ pin
21 2 flat washer
22 2 cotter pin
23 8 setscrew
24 8 cap plug
25 2 flat bar
27 1 handle
28 2 rubber seal
29 2 drive screw
31 1 chain assembly
34 1 clamp ring pivot pin
36 1 flat washer
37 1 Esna™ nut
38 1 pressure warning lock screw
39 1 warning pad
40 1 Buna-N O-ring
41 1 bushing
42 12 drive screw
43 1 instructions (not shown)
44 1 caplug
NOTE: Item numbers correspond with TDW Assembly Drawing 19-3716-0600-SUF and the numbering on
page 14.
