409-10204
Rev G
Figure 16
8. TROUBLESHOOTING
Contact the Support Center at 1-800-522-6752.
8.1. Error Codes
See the table in Figure 17 for a listing of error codes.
ERROR CODE ERROR DESCRIPTION
E001 The host is inhibiting operation.
E002
The guard interlock is open.
E003 The insert interlock is open
E004
The safety circuit is not operational.
E005
Control panel is not communicating with the CPU board.
E020
Movement of the TDC switch was not detected.
E021
The TDC switch was not made.
E099 Host Module not detected
E100
Stuck keypad button
E101 Footswitch input stuck on
Figure 17
To Next Page
