TASCAM MD-CD1 RS-232C Protocol Specification
29 TEAC Corporation
AUTO TRACK SELECT RETURN
This is the return command in response to the command "AUTO TRACK SELECT [31]."
It returns the Auto Track on/off status.
Command B1
Machine ID 0
Data 2 bytes
Data 1 Data 2 Description Remarks
0 0 Auto Track Off
0 1 Auto Track On
(Level)
Auto Track is executed according to the specified AUTO
TRACK LEVEL.
0 2 Auto Track On
(Digital
Direct)
Auto Track is executed according to the track data within
the S/P DIF signal.
0 3 Auto Track On
(Time)
Auto Track is executed according to the specified AUTO
TRACK TIME.
Request/Preset AUTO TRACK SELECT [31]
EOM TRACK TIME RETURN
This is the return command in response to the command "EOM TRACK TIME PRESET [32]."
It returns the time at which the EOM (End Of Message) function will give notice that the end of the
track is near.
Command B2
Machine ID 0
Data 2 bytes
Data 1 Data 2 Description Remarks
0 0 EOM Track
Off
N1 N2 Number of
seconds
N1: Tens digit of seconds, N2: Ones digit of seconds
Request/Preset EOM TRACK TIME PRESET [32]
EOM DISC TIME RETURN
This is the return command in response to the command "EOM DISC TIME PRESET [33]."
It returns the time at which the EOM (End Of Message) function will give notice that the end of the
disc is near.
Command B3
Machine ID 0
Data 2 bytes
Data 1 Data 2 Description Remarks
0 0 EOM Disc Off
N1 N2 Number of
seconds
N1: Tens digit of seconds, N2: Ones digit of seconds
Request/Preset EOM DISC TIME PRESET [33]
PITCH CONTROL SELECT RETURN
This is the return command for the command "PITCH CONTROL SELECT [35]."
It returns the Pitch Control on/off status.
Command B5
Machine ID 0
Data 2 bytes
Data 1 Data 2 Description Remarks
0 0 Pitch Control Off
0 1 Pitch Control On
