−6−
EXPLODED VIEW-1
REF.NO. PARTSNO. DESCRIPTION REMARKS
1‑1 * M00941100A TOPPANEL
1‑2 M00260101A COLLAR,SCREW(S)
1‑3 M00260100A COLLAR,SCREW(L)
1‑4 * M00940501A SIDEPANEL,L
1‑5 * M00940601A SIDEPANEL,R
1‑6 * M00940800A ENDCAP
1‑7 * M00940700A FRONTPANEL,CAP
1‑8 * M00942900A BRACKET,CAPL
1‑9 * E95133800A PCBASSY,TOGGLED
1‑10 * M01379700A BRACKET,PCBLED
1‑11 M00481000A LENS
1‑12 * M00409500A HOLDER,BUTTON(A)
1‑13 * 5801070200 PWRSPR
1‑14 M00941500A BUTTONASSY,POWER
1‑15 * M01380700A PLATE,BUTTON
1‑16 M00701600A CPRSNSPRING,BUTTON
1‑17 M01379900A ESCUTCHEON,BTTN
1‑18 M01379800A BUTTON,D5
1‑19 * M01380800A COVER,FL
1‑20 * M01378400A PANEL,SUB
1‑21 * M01254700A FILTER
1‑22 * M01380300A SPACER,LENS
1‑23 * M01380200A HOLDER,LENS
1‑24 * M01380100A HOLDER,BUTTON
1‑25 * M00404600A CPRSNSPRING,KNOB
1‑26 M00393102A BUTTONASSY,D=8BR
1‑27 M01380000A ESCUTCHEON,FRONT
1‑28 * 5801533720 NAMEPLATE,TEAC(BLK.BLK)
1‑29 * M01383200A FRONTPANEL
1‑30 M01380400A KNOB,D44
1‑31 * M01517901A CHASSIS,BASE
1‑32 M01494801A FOOT(A),HEX21
1‑33 M00689100A CUSHION,TRAY
1‑34 M01494900A FOOT(B)
1‑35 M01495000A STAND,FOOT
1‑41 * 5801539500 SCREW,HEXAGON3X8BLACK
1‑42 * B00023000A SCREW,HEXAGON3X17.5BLACK
1‑43 * 5780023005 SCREW,BPA3X5NB
1‑44 * 5783033006 SCREW,S‑TITEBINDM3X6
1‑45 * 5780023006 SCREW,BPA3X6NB
1‑46 * 5783533008 SCREW,BPB3X8NB
1‑47 * 5786002500 ERING,E‑2.5(JIS)
1‑48 * 5780023008 SCREW,BPA3X8NB
1‑49 * B00090900A SCREW,VPBR3X8FNB
1‑50 * 5783113006 SCREW,ZPAT3X6NB
1‑51 * B00091000A SCREW,VPBR3X10FNB
