REF.NO.
PARTSNo. DESCRIPTION  REMARKS
C718,C719 12911308 CAPACITORCC25VF0.10UFZ
C720,C740 C0042624 CQ,16V0.1UFMECPU
C721,C741 C0042610 CE,10V100UFMMV-AX
C722,C723 12911308 CAPACITORCC25VF0.10UFZ
C724,C725 C0040520 CE,6.3V1000UFMMV-AX
C726,C727 C0037294 CS,6.3V47UFM3528
C732,C733 12911308 CAPACITORCC25VF0.10UFZ
C735,C755 C0001414 CC,CH50V18PFJ1608
C736,C756 C0001474 CC,CH50V33PFJ1608
C738,C739 12911308 CAPACITORCC25VF0.10UFZ
C742,C743 12911308 CAPACITORCC25VF0.10UFZ
C744,C745 C0040520 CE,6.3V1000UFMMV-AX
C746,C747 C0037294 CS,6.3V47UFM3528
C751 C0001354 CC,CH50V10PFJ1608
C752,C753 12911308 CAPACITORCC25VF0.10UFZ
C758,C759 12911308 CAPACITORCC25VF0.10UFZ
C760 C0042624 CQ,16V0.1UFMECPU
C761 C0042610 CE,10V100UFMMV-AX
C762,C763 12911308 CAPACITORCC25VF0.10UFZ
C764,C765 C0040520 CE,6.3V1000UFMMV-AX
C766,C767 C0037294 CS,6.3V47UFM3528
C901 C0007914 CC,B16V0.10UFK1608
D101-D103 S0051074 DIODE,RB520S-30
D251 S0044264 LED,SML-310LT
D301,D302 S0051074 DIODE,RB520S-30
D306 S0051074 DIODE,RB520S-30
D351 S0059304 DIODE,EC10LA03GA0
D501 S0060254 IC,AD1580ARTZ-REEL7GAX
J101,J402 E0074674 CONNECTOR,40FLT-SM1-TB
J102 E0086324 CONNECTOR,22FLT-SM1-TB
J103 5336249400 CONNECTORPLUGB04B-PH-K-S
J301 E0085664 CONNECTOR,10FLT-SM1-TB
J351 E0082990 CONNECTOR,DVIDV2R024N11
J351(DVI)-GND 5242128000 JUMPER(MANUALINS)L=5
J601 5336249800 CONNPLB08B-PH-K-SW
J602 5336249200 CONNPLB02B-PH-K-SW
J651 E0086330 JACK,YKC22-0530
J651(S)-GND 5242128000 JUMPER(MANUALINS)L=5
J701 E00831900A JACK,BNCGOLD
J702 E00831900A JACK,BNCGOLD
J703 E00831900A JACK,BNCGOLD
J705 E0074650 JACK,YKF45-3007
JP201 E0079500 JUMPERWIRE,JR-1(L=2.54)
L201 E0075424 COIL,FSLB2520-4R7MGAX
L251-L253 E0075424 COIL,FSLB2520-4R7MGAX
L351-L355 E0075424 COIL,FSLB2520-4R7MGAX
L401 E0075424 COIL,FSLB2520-4R7MGAX
L501-L504 E0075424 COIL,FSLB2520-4R7MGAX
L601,L651 E0075424 COIL,FSLB2520-4R7MGAX
L612,L622 E0086374 COIL,NLV25T-2R2J-PF
L632 E0086374 COIL,NLV25T-2R2J-PF
L711,L731 E0086344 COIL,NLV25T-R33J-PF
L712,L732 E0086354 COIL,NLV25T-1R5J-PF
L713,L714 E0075424 COIL,FSLB2520-4R7MGAX
L733,L734 E0075424 COIL,FSLB2520-4R7MGAX
L751 E0086344 COIL,NLV25T-R33J-PF
L752 E0086354 COIL,NLV25T-1R5J-PF
L753,L754 E0075424 COIL,FSLB2520-4R7MGAX
Q301 S0036084 TRANSISTOR,DTC114YKA
Q302,Q303 S0040074 FET,2SK3018
Q351 13427500 XSTR2SC2412KR,S
Q601,Q602 S0036084 TRANSISTOR,DTC114YKA
Q611,Q621 S0028584 TRANSISTOR,2SA1037AK
Q631,Q651 S0028584 TRANSISTOR,2SA1037AK
Q711,Q731 S0028584 TRANSISTOR,2SA1037AK
Q751 S0028584 TRANSISTOR,2SA1037AK
R101 R0067304 RESARRAY,1/16W4*10KJ
R103,R104 11986556 RESISTORRD1/16W10KJ
R108,R116 11986532 RESISTORRD1/16W1.0KJ
R109,R114 11986556 RESISTORRD1/16W10KJ
VIDEOPCBASSY
10
