REF.NO.
PARTSNo. DESCRIPTION  REMARKS
R111-R113 11986496 RESISTORRD1/16W33J
R115,R118 11986496 RESISTORRD1/16W33J
R117,R269 11986532 RESISTORRD1/16W1.0KJ
R119,R232 11986556 RESISTORRD1/16W10KJ
R121,R234 11986496 RESISTORRD1/16W33J
R151-R153 R0066704 RESARRAY,1/16W4*33J
R171,R172 R0066704 RESARRAY,1/16W4*33J
R201-R212 R0066704 RESARRAY,1/16W4*33J
R222-R228 R0066704 RESARRAY,1/16W4*33J
R231 R0015374 RD,1/16W22OHMJ
R237 11986496 RESISTORRD1/16W33J
R268 11986596 RESRD1/16W470KOHM5%
R270,R513 11986536 RESISTORRD1/16W1.5KJ
R271,R355 11986556 RESISTORRD1/16W10KJ
R274,R276 R0015164 RD,CHIPJUMPER(1608)
R281,R502 R0015164 RD,CHIPJUMPER(1608)
R303,R357 11986572 RESRD1/16W47KOHM5%
R305 11986548 RESISTORRD1/16W4.7KJ
R306 11986548 RESISTORRD1/16W4.7KJ
R313-R316 11986548 RESISTORRD1/16W4.7KJ
R351,R506 11986540 RESISTORRD1/16W2.2KJ
R352 11986525 RESISTORRD1/16W510J
R353 11986548 RESISTORRD1/16W4.7KJ
R354 11986532 RESISTORRD1/16W1.0KJ
R356,R401 11986556 RESISTORRD1/16W10KJ
R402,R404 11986556 RESISTORRD1/16W10KJ
R403 R0015164 RD,CHIPJUMPER(1608)
R405,R406 11986556 RESISTORRD1/16W10KJ
R504,R508 R0015164 RD,CHIPJUMPER(1608)
R507 11986540 RESISTORRD1/16W2.2KJ
R509,R517 R0015164 RD,CHIPJUMPER(1608)
R510,R511 11986532 RESISTORRD1/16W1.0KJ
R512,R514 11986556 RESISTORRD1/16W10KJ
R515 R0129314 RD,1/16W680OHMD1608
R516,R522 R0129464 RD,1/16W3.0KOHMD1608
R523 R0129084 RD,1/16W75OHMD1608
R601,R615 11986536 RESISTORRD1/16W1.5KJ
R611,R612 R0129274 RD,1/16W470OHMD1608
R613 R0015164 RD,CHIPJUMPER(1608)
R614,R624 11986496 RESISTORRD1/16W33J
R621,R622 R0129274 RD,1/16W470OHMD1608
R623,R633 R0015164 RD,CHIPJUMPER(1608)
R631,R632 R0129274 RD,1/16W470OHMD1608
R634,R718 11986496 RESISTORRD1/16W33J
R635,R625 11986536 RESISTORRD1/16W1.5KJ
R650 R0015164 RD,CHIPJUMPER(1608)
R653 11986549 RESISTORRD1/16W5.1KJ
R654-R656 R0129064 RD,1/16W62OHMD1608
R657,R702 11986556 RESISTORRD1/16W10KJ
R658-R660 11986588 RESISTORRD1/16W220KJ
R703,R716 11986556 RESISTORRD1/16W10KJ
R710,R730 11986546 RESISTORRD1/16W3.9KJ
R711,R715 R0129194 RD,1/16W220OHMD1608
R712,R721 R0015164 RD,CHIPJUMPER(1608)
R714,R724 R0129274 RD,1/16W470OHMD1608
R717,R731 R0129194 RD,1/16W220OHMD1608
R720,R740 11986534 RESISTORRD1/16W1.2KJ
R723,R736 11986556 RESISTORRD1/16W10KJ
R725,R734 R0129274 RD,1/16W470OHMD1608
R726,R727 R0129084 RD,1/16W75OHMD1608
R732,R741 R0015164 RD,CHIPJUMPER(1608)
R735,R737 R0129194 RD,1/16W220OHMD1608
R738,R758 11986496 RESISTORRD1/16W33J
R743,R756 11986556 RESISTORRD1/16W10KJ
R744,R745 R0129274 RD,1/16W470OHMD1608
R746,R747 R0129084 RD,1/16W75OHMD1608
R750 11986546 RESISTORRD1/16W3.9KJ
R751,R755 R0129194 RD,1/16W220OHMD1608
R752,R761 R0015164 RD,CHIPJUMPER(1608)
R754,R764 R0129274 RD,1/16W470OHMD1608
VIDEOPCBASSY
