REF.NO.
PARTSNo. DESCRIPTION REMARKS
C1317,C1318 5263167923 C,FILM0.10UF50VJVT
C1319 5181761000 JUMPERP=5.0
C1320 5242117400 JUMPER(INS)JPW-L5
C1321,C1322 5263167923 C,FILM0.10UF50VJVT DM
C1321,C1322 5181761000 JUMPERL=5.0 EXP
C1323 5263315320 C,FILM0.010UF50VJVT
C1501 C0007914 CC,B16V0.10UFK1608
C1502 C0036264 CE,10V47UFMSVP
C1508,C1511 C0007914 CC,B16V0.10UFK1608
C1509,C1512 C0007510 CE,16V47UFMSA
C1510 C0040464 CC,CH50V1000PFJ1608
C1513,C1519 C0038234 CC,B10V1.0UFK1608
C1514 C0004064 CC,CH50V100PFJ1608
C1515,C1517 C0007914 CC,B16V0.10UFK1608
C1516,C1532 C0036174 CE,10V33UFMSVP
C1518,C1526 C0036264 CE,10V47UFMSVP
C1520,C1523 C0002244 CC,B50V0.010UFK1608
C1521,C1524 C0035340 CE,16V100UFMSA
C1522 C0038234 CC,B10V1.0UFK1608
C1525,C1527 C0007914 CC,B16V0.10UFK1608
C1528,C1530 C0036264 CE,10V47UFMSVP
C1529,C1531 C0007914 CC,B16V0.10UFK1608
C1533,C1535 C0007914 CC,B16V0.10UFK1608
C1534 C0036264 CE,10V47UFMSVP
C1536,C1538 C0036264 CE,10V47UFMSVP
C1537 C0007914 CC,B16V0.10UFK1608
C1601,C1603 5263167923 C,FILM0.10UF50VJVT
C1602 5260531420 CE,100UF20VMSAVT
C1604 5260485000 CE,1000MF16VASFVE
C1605 5263167923 C,FILM0.10UF50VJVT
D1101,D1102 5224016420 DIOS5688GTAPING
D1201,D1202 5224016420 DIOS5688GTAPING
D1301-D1304 S0059291 DIODE,21DQ04GA0
J1101 E00353701A JACK,RCA1PWHITENICKING
J1102,J1202 E0110250 CONNECTOR,XLM-3-32PCV-FG
J1201 E00353801A JACK,RCA1PREDNICKING
K1101,K1102 5290015600 RLYA-12W-K
K1201,K1202 5290015600 RLYA-12W-K
L1301-L1303 5286033920 CHC10UHK(LAP2T)VT
L1501,L1603 5286033920 CHC10UHK(LAP2T)VT
L1502 5286033920 CHC10UHK(LAP2T)VT
L1601,L1602 5286033920 CHC10UHK(LAP2T)VT
L1604,L1605 5286033920 CHC10UHK(LAP2T)VT
P1001 E0074674 CONNECTOR,40FLT-SM1-TB
P1003 E0074663 CONNECTOR,15FMN-BTK-A
P1005 5336249300 CONNPLB03B-PH-K-SW
P1301,P1304 5336303200 CONNPLB2B-EHW
P1302,P1305 5336303300 CONNPLB3B-EHW
P1303,P1306 5336307300 CONNPLB3B-EH-YY
P1501 5336251200 CONNPLB02B-PH-K-RR
P1502 5336250000 CONNPLB10B-PH-K-SW
P1503 5336249200 CONNPLB02B-PH-K-SW
P1505 5336249600 CONNPLB06B-PH-K-SW
Q1101,Q1102 5232255620 DTRDTC114ESA
Q1201,Q1202 5232255620 DTRDTC114ESA
Q1601,Q1603 S0057224 FET,MCH3306-TL-EGXX
Q1602,Q1604 S0022044 TRANSISTOR,DTC114EUA-T106
R1001-R1003 R0015454 RD,1/16W47OHMJ
R1028-R1031 R0015454 RD,1/16W47OHMJ
R1032,R1045 11986738 CHIPJUMPER(1.6*0.8)
R1033,R1034 11986493 RESRD1/16W24OHM5%
R1036 11986493 RESRD1/16W24OHM5%
R1037 R0016174 RD,1/16W47KOHMJ
R1038 11986499 RESRD1/16W43OHM5%
R1039,R1041 R0132464 RD,1/16W47OHMG1608A DM
R1039,R1041 R0015534 RD,1/16W100OHMJ EXP
R1040,R1043 R0132464 RD,1/16W47OHMG1608A
R1042 R0132464 RD,1/16W47OHMG1608A DM
R1042 R0015534 RD,1/16W100OHMJ EXP
R1046,R1047 R0015454 RD,1/16W47OHMJ
DACPCBASSY
14
