REF.NO.
PARTSNo. DESCRIPTION REMARKS
R1050,R1051 R0016174 RD,1/16W47KOHMJ
R1052-R1055 11986738 CHIPJUMPER(1.6*0.8)
R1101,R1102 R0100461 RD,1/4W2.2OHMJ
R1103,R1203 R0108681 RN,1/4W1.5KOHMFL=10
R1104,R1105 R0100461 RD,1/4W2.2OHMJ
R1106-R1108 R0108801 RN,1/4W4.7KOHMFL=10
R1109,R1110 R0100461 RD,1/4W2.2OHMJ
R1111-R1114 R0108871 RN,1/4W9.1KOHMFL=10
R1115 R0108481 RN,1/4W220OHMFL=10
R1117,R1118 5286033920 CHC10UHK(LAP2T)VT
R1119-R1122 R0108871 RN,1/4W9.1KOHMFL=10
R1123,R1129 R0108511 RN,1/4W300OHMFL=10
R1125-R1128 R0108871 RN,1/4W9.1KOHMFL=10
R1131,R1231 R0109041 RN,1/4W47KOHMFL=10
R1201,R1202 R0100461 RD,1/4W2.2OHMJ
R1204,R1205 R0100461 RD,1/4W2.2OHMJ
R1206-R1208 R0108801 RN,1/4W4.7KOHMFL=10
R1209,R1210 R0100461 RD,1/4W2.2OHMJ
R1211-R1214 R0108871 RN,1/4W9.1KOHMFL=10
R1215 R0108481 RN,1/4W220OHMFL=10
R1217,R1218 5286033920 CHC10UHK(LAP2T)VT
R1219-R1222 R0108871 RN,1/4W9.1KOHMFL=10
R1223,R1229 R0108511 RN,1/4W300OHMFL=10
R1225-R1228 R0108871 RN,1/4W9.1KOHMFL=10
R1501,R1502 R0015574 RD,1/16W150OHMJ
R1504 R0015454 RD,1/16W47OHMJ
R1508,R1526 R0015454 RD,1/16W47OHMJ
R1510 R0015454 RD,1/16W47OHMJ
R1511,R1512 R0015534 RD,1/16W100OHMJ
R1513 R0016114 RD,1/16W27KOHMJ
R1514,R1515 R0129354 RD,1/16W1.0KOHMD1608
R1516,R1517 R0015774 RD,1/16W1.0KOHMJ
R1518 R0132464 RD,1/16W47OHMG1608A
R1519 R0015534 RD,1/16W100OHMJ
R1520,R1522 R0132464 RD,1/16W47OHMG1608A
R1521,R1523 R0016174 RD,1/16W47KOHMJ
R1527 R0016014 RD,1/16W10KOHMJ
R1528,R1529 R0015774 RD,1/16W1.0KOHMJ
R1530-R1532 R0016014 RD,1/16W10KOHMJ
R1533,R1534 R0016174 RD,1/16W47KOHMJ
R1601,R1603 11986580 RESISTORRD1/16W100KJ
R1602,R1604 11986524 RESISTORRD1/16W470J
U1002,U1005 S0053144 IC,TC74VHC157FT
U1003 S0053193 IC,SM5847AF
U1004,U1510 S0053204 IC,BU2288FV-E2
U1006 S0053154 IC,TC74VHC04FT
U1007 S0053164 IC,TC74VHCT08AFT
U1008 S0051944 IC,TC74VHC74FT
U1009 S0053164 IC,TC74VHCT08AFT
U1101,U1102 S0037410 IC,PCM1704U
U1103,U1104 S0060214 IC,AD825ARZ-REEL7GAX
U1105,U1205 S0058820 IC,OP42GP
U1106,U1206 S0049770 IC,LM6172IN
U1201,U1202 S0037410 IC,PCM1704U
U1203,U1204 S0060214 IC,AD825ARZ-REEL7GAX
U1301,U1304 13447952 ICLINNJM7805FA
U1302,U1602 S0051390 IC,NJU7223F33
U1305 13447969 ICLINNJM7905FA
U1306 13447956 ICLINNJM7812FA
U1307 13447973 ICLINNJM7912FA
U1501 S0053114 IC,TC7SET08F
U1505 5220123500 ICDGTLMC74HC4046AFELG
U1506 S0053134 IC,TC7WHU04FU
U1507 S0034844 IC,TC74HC4053AFT(EL)
U1508 E0085634 VCXO,COC22AXT25.92MHZ
U1509 E0085624 VCXO,COC22AXT27MHZ
U1511 S0053174 IC,TC74VHC86FT
U1512 S00539000B IC,WORDPLLV1.10
U1601 13447952 ICLINNJM7805FA
DACPCBASSY
15
