Teac Esoteric UX-3 - Page 18

REF.NO.
PARTSNo. DESCRIPTION REMARKS
R1151 11986500 RESRD1/16W47OHM5%
R1152,R1319 R0067304 RESARRAY,1/16W4*10KJ
R1171 11986500 RESRD1/16W47OHM5%
R1172 11986548 RESISTORRD1/16W4.7KJ
R1173,R1301 11986532 RESISTORRD1/16W1.0KJ
R1174-R1177 11986500 RESRD1/16W47OHM5%
R1178 11986556 RESISTORRD1/16W10KJ
R1302 11986540 RESISTORRD1/16W2.2KJ
R1304 11986520 RESRD1/16W330OHM5%
R1306 R0016334 RD,1/16W220KOHMJ
R1307 11986540 RESISTORRD1/16W2.2KJ
R1308,R1330 11986564 RESRD1/16W22KOHM5%
R1312,R1313 11986532 RESISTORRD1/16W1.0KJ
R1321,R1323 11986556 RESISTORRD1/16W10KJ
R1322 11986532 RESISTORRD1/16W1.0KJ
R1324 11986532 RESISTORRD1/16W1.0KJ
R1325 R0067304 RESARRAY,1/16W4*10KJ
R1326 11986556 RESISTORRD1/16W10KJ
R1331 11986564 RESRD1/16W22KOHM5%
R1332,R1334 11986532 RESISTORRD1/16W1.0KJ
R1333,R1335 11986500 RESRD1/16W47OHM5%
R1336 11986532 RESISTORRD1/16W1.0KJ
R1337 11986532 RESISTORRD1/16W1.0KJ
R1338 11986532 RESISTORRD1/16W1.0KJ
U1007 S0059283 IC,TSB43CA42PGFG4GA0
U1101 S0053004 IC,AK4112BVF-E2
U1102 S0057034 IC,SN74CBTLV3257PWRGXX
U1105 S0057044 IC,SN74AHC1GU04DCKGXX
U1109,U1110 S0049493 IC,TC74VHC541FTTSSOP
U1151 S00584900A IC,SIFPLDBVFV1.00
U1302 S0060310 IC,PQ3RF33JGZ0
U1304 S0052944 IC,TC7SET08FU(TE85L)
U1305 S0057054 IC,M62705MLGXX
U1306 S00571500C IC,ROMSIFV1.11
U1307 S00571400C IC,MPUSIFV1.11
U1308 S0057044 IC,SN74AHC1GU04DCKGXX
X1001 E0095504 RESONATOR,LIM55A-T24MGXX
X1301 E0095494 RESONATOR,LIM55A-T16MGXX
1394BVFPCBASSY
18
