REF.NO.
PARTSNo. DESCRIPTION  REMARKS
E95231600A PCBASSY,DATAJCT
E90231600A PCB,DATAJCT
E0095420 TERMINAL,M1866-AGZ0
C3001,C3003 C0007914 CC,B16V0.10UFK1608
C3002,C3004 C0036264 CE,10V47UFMSVP
C3005,C3007 C0007914 CC,B16V0.10UFK1608
C3006,C3008 C0036264 CE,10V47UFMSVP
C3009 C0007914 CC,B16V0.10UFK1608
C3010 C0036264 CE,10V47UFMSVP
C3012,C3013 C0007914 CC,B16V0.10UFK1608
P3001 13124424 CONNECTORZHB2B-ZR
P3002-P3004 E0074674 CONNECTOR,40FLT-SM1-TB
R3004-R3010 11986500 RESRD1/16W47OHM5%
R3014-R3034 11986500 RESRD1/16W47OHM5%
R3035,C3011 11986738 CHIPJUMPER(1.6*0.8)
R3036-R3044 11986500 RESRD1/16W47OHM5%
R3045 R0016014 RD,1/16W10KOHMJ
RA3003-RA3006 R0066744 RESARRAY,1/16W4*47J
RA3009-RA3012 R0066744 RESARRAY,1/16W4*47J
U3002-U3004 S0049493 IC,TC74VHC541FTTSSOP
DATAJCTPCBASSY
19
