Teac Esoteric UX-3 - PCB Assemblies Overview; Front, Power LED, and D-Out PCBs

REF.NO.
PARTSNo. DESCRIPTION REMARKS
E95232100A PCBASSY,FRONTUX-3
E95232120A PCBASSY,FRONTUX-3T/C
E95232150A PCBASSY,FRONTUX-3EUR
E95232104A PCBASSY,FRONTUX-3KOR
E90181900D PCB,FRONT
M00539300A HOLDERASSY,FL
5801532101 FLGDE
M00539400A CUSHION,
M0029800 SPACER,LEDLH-3-4
M0176070 HOLDER,LEDLF-10
C1,C3,C4 5263167923 C,FILM0.10UF50VJVT
C11,C13,C15 5263167923 C,FILM0.10UF50VJVT
C12 5263310520 C,FILM100PF50VJVT
C16,C17,C19 5263167923 C,FILM0.10UF50VJVT
C2,C14,C18 5260462720 CE,47UF25VMAUVT
C20 5263167923 C,FILM0.10UF50VJVT
D1,D3 S0052200 LED,SLR343BCT3F
D10 5224015020 DIO1SS133T-77FT
D11-D13 S0054560 LED,SLI-343Y13F
D18,D19 S0052200 LED,SLR343BCT3F
D20 S0052200 LED,SLR343BCT3F
D21,D22 S0052200 LED,SLR343BCT3F
D23 S0052200 LED,SLR343BCT3F
D4,D6 S0052200 LED,SLR343BCT3F
D7,D9 S0052200 LED,SLR343BCT3F
FL1 E00746900B ELCTRNRAYDSPL,CM2058GG
JP1 5181761000 JUMPERP=5.0 T/C
JP2 5181761000 JUMPERP=5.0 KOR
JP3 5181761000 JUMPERP=5.0 EUR
JP6 5242117400 JUMPER(INS)JPW-L5
L1 5286033920 CHC10UHK(LAP2T)VT
P1 5336253700 CONNPLB07B-PH-K-Y
P10 5336249800 CONNPLB08B-PH-K-SW
P2 5336249900 CONNPLB09B-PH-K-SW
P3 E0085664 CONNECTOR,10FLT-SM1-TB
P4 5336250000 CONNPLB10B-PH-K-SW
P5,P7 5336249300 CONNPLB03B-PH-K-SW
P6 5336255900 CONNPLB09B-PH-K-KBK
Q1-Q5 5232255620 DTRDTC114ESA
Q6 5232255620 DTRDTC114ESA
Q7 5232254720 DTRDTA114ESA
R1,R2,R11 R0101341 RD,1/4W10KOHMJ
R12 R0101101 RD,1/4W1.0KOHMJ
R13 R0101121 RD,1/4W1.2KOHMJ
R14 R0101141 RD,1/4W1.5KOHMJ
R15 R0101181 RD,1/4W2.2KOHMJ
R16 R0101221 RD,1/4W3.3KOHMJ
R17-R19 R0100941 RD,1/4W220OHMJ
R20 R0101461 RD,1/4W33KOHMJ
R22 R0101441 RD,1/4W27KOHMJ
R23 R0101501 RD,1/4W47KOHMJ
R24,R32 R0101341 RD,1/4W10KOHMJ
R25 R0100941 RD,1/4W220OHMJ
R26 R0100941 RD,1/4W220OHMJ
R27,R41 R0101341 RD,1/4W10KOHMJ
R28 R0100941 RD,1/4W220OHMJ
R29 5242117400 JUMPER(INS)JPW-L5
R33-R38 R0100781 RD,1/4W47OHMJ
R39,R40 R0100701 RD,1/4W22OHMJ
R3-R10 R0100781 RD,1/4W47OHMJ
SW1-SW7 E0082440 SW,TACTSKHHDGA010
U1 S00590600D IC,MPUFRONTUX-3V2.03
U2 S0051434 IC,BR93L46RF-W
U3 S0021414 IC,TC74VHCT04
U4 S0018723 &IC,M66004FP
U5 S0053230 IC,RPM7238-H91
U6 S0051390 IC,NJU7223F33
U7 S0047794 FC,TC74VHCT08AF
U8 S0057054 IC,M62705MLGXX
X1 E0022490 RESONATOR,EFO-EC5004A4
FRONTPCBASSY
5
