Teac Esoteric UX-3 - Page 6

REF.NO.
PARTSNo. DESCRIPTION REMARKS
E95233800A PCBASSY,PWRLEDUX-3
E90182000A PCB,PWRLED
D15,D16 S0052200 LED,SLR343BCT3F
D24 S0052200 LED,SLR343BCT3F
P9 5336249300 CONNPLB03B-PH-K-SW
Q10 5232255620 DTRDTC114ESA
R31 R0100941 RD,1/4W220OHMJ
REF.NO.
品目コー
ド
品目テキスト REMARKS
E95182100A PCBASSY,D-OUT
E90182100B PCB,D-OUT
M01650800A WASHER,JACKBNC
M01650900A NUT,JACKBNC
13180156 TERM(P-424)
5780202606 CCREW,FLATM2.6X6
C1001,C1003 5263167923 C,FILM0.10UF50VJVT
C1002,C1007 C0007510 C,ELECT16V47UFMSA
C1004 5260462220 C,ELECT33UF25VMAUVT
C1005,C1006 5263167923 C,FILM0.10UF50VJVT
C1008 5263167923 C,FILM0.10UF50VJVT
J1002 E00856700A JACK,RCA1PORGNICKING
J1003 E00831900A JACK,BNCGOLD
P1003 5336249400 CONNECTORPLUGB04B-PH-K-S
P1004 5336251200 CONNPLB02B-PH-K-RR
R1001 R0100861 RD,1/4W100OHMJ
R1002 R0100831 RD,1/4W75OHMJ
T1001 5320046300 TRANS,PULSETC-1027-04
U1001 5220093600 ICDGTLTC74HCU04AF-TP2
U1002-U1004 E0100982 FILTER,100PF
U1005 E0110220 OPTCONN,GP1FA513TZ0FGZX
D-OUTPCBASSY
PWRLEDPCBASSY
6
