REF. NO
EXPLODED VIEW-1
PARTS NO.
DESCRIPTION
REMARKS
1-59
1-60
1-53
GR-10i/SR-L200i
05-04GR10I00000
LCD PCB ASSY (GR-10i) (SR-L200i) [T/C] - BLACK
1-55
1-54
05-05GR10I00000
KEY PCB ASSY
05-08GR10I00000
IP PCB ASSY
1-56
68-112323161000
METAL WASHER 3.2X16X1MM
1-57
18-203SLD881190
TRANSFORMER EI48 120V/60HZ [T/C]
1-50
1-51
1-52
18-206GR10I0190
TRANSFORMER EI48 240V/50HZ [AUS]
19-021082800020
SPEAKER 8W 4 OHM
05-01GR10I00000
MAIN/TUNER PCB ASSY [T/C]
05-01GR10I00010
MAIN/TUNER PCB ASSY [AUS]
56-43GR10I08000
REMOTE FRONT CABINET - SILVER (GR-10i)
56-43GR10I0B000
56-43GR10I09000
REMOTE FRONT CABINET - BLACK (SR-L200i)
REMOTE FRONT CABINET - WHITE (SR-L200i)
1-58
56-43GR10I18000
REMOTE REAR CABINET - SILVER (GR-10i)
REMOTE REAR CABINET - BLACK (SR-L200i)
REMOTE REAR CABINET - WHITE (SR-L200i)
56-43GR10I1B000
56-43GR10I19000
56-44GR10I08000
BATTERY DOOR - SILVER (GR-10i)
BATTERY DOOR - BLACK (SR-L200i)
BATTERY DOOR - WHITE (SR-L200i)
56-44GR10I0B000
56-44GR10I09000
57-33GR10I00220
REMOTE PLATE “TEAC”- WHITE (GR-10i)
57-33GR10I00120
REMOTE PLATE “TEAC” - BLACK (SR-L200i)
57-33GR10I00020
REMOTE PLATE “TEAC” - WHITE (SR-L200i)
1-61
61-11GR10I00020
WEIGHT STEEL
1-62
61-25GR10I00020
REMOTE BATTERY PLATE (+)
1-63
61-25M020800120
BATTERY PLATE (-)
1-64
66-140520170121
SLEF-TAPPING SCREW TB/KH 2X7MM
1-65
05-13GR10I00000
REMOTE PCB ASSY
1-66
51-021301000080
LITHIUM BATTERY
1-67
61-11SLD88M0020
WEIGHT IRON
1-68
66-140226160321
SLEF-TAPPING SCREW TA/BH 2.6X6MM
9
!
!
05-04GR10I00010
LCD PCB ASSY (SR-L200i) [T/C]- WHITE
05-04GR10I00020
LCD PCB ASSY (SR-L200i) [AUS] - WHITE
05-04GR10I00021
LCD PCB ASSY (SR-L200i) [AUS] - BLACK
