Sampling Frequency and Number of Channels
1-13
102.4 kHz Series
Sampling Frequency (kHz) Bandwidth (kHz)
No 16bits 2ch 32bits 1ch 32bits 2ch
*102.4 42 4 2 2 N/A
*51.2 21 8 4 4 4
25.6 1016888
12.8 5 32 24 24 24
5.12 2 32323232
2.56 1 32323232
1.28 0.53 32 32 32 32
100 kHz Series
Sampling Frequency (kHz) Bandwidth (kHz)
No 16bits 2ch 32bits 1ch 32bits 2ch
*100 41 4 2 2 N/A
*50 20 8 4 4 4
20 8 16 8 8 8
10 4.1 32 24 24 24
5 2 32 32 32 32
2 0.8 32 32 32 32
1 0.4 32 32 32 32
96 kHz Series
Sampling Frequency (kHz) Bandwidth (kHz)
No 16bits 2ch 32bits 1ch 32bits 2ch
*96 40 4 2 2 N/A
*48 20 8 4 4 4
24 10 16 8 8 8
12 5 32242424
6 2.5 32 32 32 32
3 1.2532323232
1.5 0.625 32 32 32 32
65.536 kHz Series
Sampling Frequency (kHz) Bandwidth (kHz)
No 16bits 2ch 32bits 1ch 32bits 2ch
*65.536 27 4 2 2 N/A
*32.768 13 8 4 4 4
16.384 6 16 8 8 8
8.192 3 32242424
4.096 1.7 32 32 32 32
2.048 0.8 32 32 32 32
1.024 0.4 32 32 32 32
Max. number of analog input channels based on the tachometer input setting
Max. number of analog input channels based on the tachometer input setting
Max. number of analog input channels based on the tachometer input setting
Max. number of analog input channels based on the tachometer input setting
Sampling Frequency and Number of Channels
A combination of the sampling frequency vs. the number of analog input channels is varied depending on the
selected recording mode, such as, the type of the recording media and the number of tachometer input
channels.
Recording Condition 1
Recording Mode: Media recording to MO or PC card, while transferring data to PC
Memo Voice Recording: ON or OFF
Interface to PC: IEEE1394 or Ethernet
Remarks: Cannot select the moving average other than 1 (one) at the Sampling Frequency settings shown
with *(asterisk).
