Installing LX-10/20 IEEE 1394 Version
2-5
Installing OHCI Driver
For Windows 2000/XP
The following screen examples are for Windows 2000. Follow the same procedures for Windows XP.
1. Insert the CBFW3 to the CardBus PC card slot, or insert the PCIFW3, then turning on your PC. The
standard Windows driver will be automatically installed. Follow the below procedures to confirm the driver
has been installed correctly
.
2. Double click [Control Panel] from [My Computer］.
Double click ［System］ to open the dialog box.
3.Click ［Hardware］ tab, and then click ［Device Manager(D)］.
4. Double click ［1394Bus Host Controller］, and confirm “Texas Instruments OHCI Compliant IEEE 1394 Host
Controller” is added to indicate the driver software has been correctly installed.
Now the OHCI driver installation has been completed, next proceed to the LX Series device driver installation.
To Next Page
