MC-DX33
REF.NO PARTS NO. DESCRIPTION REMARKS
05-DX33S0100000 MAIN PCBA
48-01DX33B00220 MAIN PCB 94HB 137x92x1.6mm
CN1,2 43-022200130120 WAFER 2mm 3P 90C
CN203 43-022250120221 WAFER 2.5mm 2P 90C (BLACK)
CN204 44-535316052520 2P RAINBOW WIRE 160mm HSG+TML(2) AA
CN207 44-555260052621 2P COAXIAL CABLE L=60mm HSG+TML(2) AA
CN501,502 43-022200130120 WAFER 2mm 3P 90C
CN504 43-022200140120 WAFER 2mm 4P 90C
CN508 43-022200170120 WAFER 2mm 7P 90C
CN511 43-022150212120 WAFER 12P 1.5mm 90C
CN-DC 43-462103003321 D-S TERMINAL #DSW-31 R1
D701,702,703,704 12-RL2020000021 RECTIFIER DIODE RL-202 2A 100V
D708 12-1N40010000P1 RECTIFIER DIODE 1N4001 (T=52mm)
D400,705 12-1N4148000125 DIODE 1N4148 (T=52mm)
D603 12-SS1400000025 SMD DIODE SS14 SMA/DO-214AC
D601 12-1N5819000021 RECTIFIER DIODE 1N5819
IC101 16-GY6550000021 MCU GY655 GENNY (80PIN QFP80)
IC501 16-LC7534200021 IC (SANYO) LC75342-E DIP30SD
IC703 16-SC1308000021 IC (LIBERAL) SC1308-01
L401,402,405 38-013100050120 AXIAL INDUCTOR 10UH +-10% 350mA EC-24
L403 32-031351600025 FERRITE BEAD 3.5x6x0.8TB (TAPING)
L404,406 38-013100050120 AXIAL INDUCTOR 10UH +-10% 350mA EC-24
JK201 43-421000003210 COAXIAL JACK IF-01A
Q401,Q716 11-8050C0000025 TRANSISTORS 2W 8050C (TAPING)
Q405,406 11-MMBT39040221 SMD TRANSISTORS MMBT3904 SOT23
Q501 11-MMBT39040221 SMD TRANSISTORS MMBT3904 SOT23
Q502 11-MMBT39040221 SMD TRANSISTORS MMBT3904 SOT23
Q701,707 11-9015C0000021 PNP TRANSISTORS 9015C
Q703 16-KA7808000221 IC (SAMSUNG) KA7808E (TO-220)
Q704 11-KSB772YS0021 TRANSISTORS KSB772YS (SAMSUNG)
Q705 11-MMBT39040221 SMD TRANSISTORS MMBT3904 SOT23
Q706,715 11-9014C0000025 NPN TRANSISTORS 9014C (TAPING)
Q712,713 11-ST8550C00026 TRANSISTOR ST8550C (TSK) TAPING TO-92
ZD401 12-011470320125 ZENER DIODE +-5% 4.7V 1/2W (T=52mm)
ZD501 12-011680320125 ZENER DIODE +-5% 6.8V 1/2W (T=52mm)
ZD701 12-012110320125 ZENER DIODE +-5% 11V 1/2W (T=52mm)
MAIN PCB ASSY
5 PC BOARDS AND PARTS LIST
