Teac MC-DX33 - Exploded View And Parts List

7
MC-DX33
REF.NO PARTS NO. DESCRIPTION REMARK
1-1 56-04DX2200B070 FRONT CABINET (BLK)
56-04DX2200A040 FRONT CABINET (SILVER)
1-2 56-05DX2200B010 REAR CABINET (BLK)
56-05DX2200A010 REAR CABINET (SILVER)
1-3 56-07DX3300B010 VOLUME BOTTOM HOLDER (BLK)
56-07DX3300A000 VOLUME BOTTOM HOLDER (SILVER)
1-4 56-07DX3302B010 VOLUME COVER -R (BLK)
56-07DX3300A010 VOLUME COVER -R (SILVER)
1-5 56-07DX22039000 CD DESK BKT
1-6 56-07DX2214B000 REMOTE BKT (BLK)
56-07DX22108000 REMOTE BKT (SILVER)
1-7 56-07DX2215B000 SHOCK ABSORBER BRACKET (BLK)
56-07DX22118000 SHOCK ABSORBER BRACKET (SILVER)
1-8 56-14DX2200B010 CD DOOR (BLK)
56-14DX2200A010 CD DOOR (SILVER)
1-9 61-68CD10100020 CD ALUM COVER
1-10 56-22DX2211B000 LED LEW COVER (BLK)
56-22DX22108000 LED LEW COVER (SILVER)
1-11 56-22DX2212B000 PROTECT COVER (BLK)
56-22DX2210A000 PROTECT COVER (SILVER)
1-12 56-24DX01500000 CD DOOR GEAR
1-13 56-24DX01510000 STRAP GEAR
1-14 56-54DX2210B000 FUNCTION KNOB GROUP-1 (BLK)
56-54DX2210A000 FUNCTION KNOB GROUP-1 (SILVER)
1-15 56-54DX2211B010 FUNCTION KNOB GROUP-2 (BLK)
56-54DX2211A010 FUNCTION KNOB GROUP-2 (SILVER)
1-16 56-54DX2211B000 PLAY KNOB GRUP (BLK)
56-54DX2212A000 PLAY KNOB GRUP (SILVER)
1-17 56-07DX3301B000 VOLUME BOTTOM HOLDER PLATE (BLK)
56-07DX3301A000 VOLUME BOTTOM HOLDER PLATE (SILVER)
1-18 56-57DX22100000 CD DOOR LENS
1-19 56-57DX22010000 BLACKLIGHT LENS
1-20 56-57DX22022000 REMOTE LENS
1-21 56-57DX22030010 DISPLAY LENS
1-22 56-07DX3303B010 VOLUME COVER-L (BLK)
56-07DX3301A010 VOLUME COVER-L (SILVER)
1-23 56-67DX22009000 PCB BRACKET
1-24 56-78DX22009000 SHINE RING
1-25 56-78DX2200G000 CD DOOR RING
1-26 45-114200500062 AC CORD UDE APP 2M (M.T) (BLK)
1-27 56-78CDX092G000 CHROME RING -SUBWOOFER BOX
1-28 61-30DX22100020 KNOB COVER
1-29 05-DX33S0100000 PCBA-MAIN
1-30 05-DX33S0200000 PCBA-TUNER
1-31 05-DX33S0400000 PCBA-DISPLAY
1-32 56-07DX22029000 BACKLIGHT BKT
1-33 57-26DX22000020 FILTER SHEET 76X37.5X0.3MM
1-34 66-140326180321 SELF-TAPPING SCREW TA/PH 2.6X8MM
1-35 05-DX33S1900000 PCBA-VOLUME
1-36 05-DX33S0900000 PCBA-HP
EXPLODED VIEW PARTS LIST
