REF.NO PARTS NO. DESCRIPTION REMARKS
05-DX33S3000000 PCBA-CD
48-30DX33B00220 CD PCB 94HB 101x97x1.6mm
CN2 43-022100212120 SMD F.F.C WAFER 1mm 12P 90C (BLACK)
CN5,6 43-022200120120 WAFER 2mm 2P 90C
CN801 43-022100216220 F.F.C.WAFER 1mm 16P 90C
CN802 43-012150160320 WAFER 1.5mm 6P 180C (DA23 & SAMSUNG CD)
CN803 44-565324056720 3+3P SHIELD/WIRE L=240mm HSG+TML/90C(2)
CN806,810 43-022200120120 WAFER 2mm 2P 90C
CN808 44-315325052520 2P WIRE L=250mm HSG(2)x1 (UL1007#26)
D800 12-1N5819000021 RECTIFIER DIODE 1N5819
D801 12-011430320125 ZENER DIODE +-5% 4.3V 1/2W (T=52mm)
IC801 16-LC78690N0121 IC (SANYO) LC78690NW-LR-UHK-E (SQFP80)
IC802 16-LA6548000121 IC (SANYO) LA6548NHL-TE-L-E
IC803 16-LB1641000021 IC (SANYO) LB1641
IC804 16-KA7806000121 IC (SAMSUNG) KA7806E (TO-220)
L801,802 38-014100050020 AXIAL INDUCTOR 100UH +-10% (T=52mm)
Q801 11-9015C0000021 PNP TRANSISTORS 9015C
Q802 11-2SB764E00021 TRANSISTORS 2SB764-E (SANYO)
X801 31-048169310120 RESONATOR 16.93MX (2PIN) (C1=C2=25PF)
CD PCB ASSY
