Teac MC-DX33 - Page 15

15
MC-DX33
REF.NO PARTS NO. DESCRIPTION REMARKS
SWITCH PCBA DOOR OPEN SENSOR
48-23DX33B00220 SWITCH PCB (1) 94HB 20x11.4x1.6mm
CN601 44-335280052720 2P RAINBOW WIRE80mm HSG(2)x1 (UL1007#30)
41-071200010020 SERIES MICRO SWITCH SD-007A
SWITCH PCB 1 ASSY
REF.NO PARTS NO. DESCRIPTION REMARKS
SWITCH PCBA DOOR CLOSE SENSOR
48-23DX33B01220 SWITCH PCB (2) 94V0 20x11.4x1.6mm
CN601A 44-335280052720 2P RAINBOW WIRE80mm HSG(2)x1 (UL1007#30)
41-071200010020 SERIES MICRO SWITCH SD-007A
SWITCH PCB 2 ASSY
REF.NO PARTS NO. DESCRIPTION REMARKS
05-DX33S0700000 POWER PCBA-SUB.
48-07DX33B00120 POWER (AMP) PCB 94V0 115x85x1.6mm
C406,701 26-017470950111 E.CAP 4700UF 35V +-20% (PH) 85C
C718,719 26-017100750121 E.CAP 1000UF 16V +-20% 105C
CN1 43-012250130120 WAFER 2.5mm 3P 180C
CN2 43-012200190120 WAFER 2mm 9P 180C
CN3 43-012200130120 WAFER 2mm 3P 180C
CN4 43-012250150120 WAFER 2.5mm 5P 180C
CN5 43-012250140120 WAFER 2.5mm 4P 180C
CN6 43-012250120120 WAFER 2.5mm 2P 180C
D301,706 12-1N40010000P1 RECTIFIER DIODE 1N4001 (T=52mm)
D701~704 12-1N5401000021 RECTIFIER DIODE 1N5401 3A 100V
D705,707 12-1N4148000125 DIODE 1N4148 (T=52mm)
D708,ZD1,ZD2 12-011390320125 ZENER DIODE +-5% 3.9V 1/2W (T=52mm)
FU2,FU3 46-055350300010 GLASS FUSE 5x20mm T3.5A/250V UL/CSA/JIS
FU4 46-055400300010 GLASS FUSE 5x20mm T4A/250V S506
Q301 11-9014C0000021 NPN TRANSISTORS 9014C
Q707.708,710 11-2SD1936T0021 TRANSISTORS 2SD1936T-SSH (SANYO)
D401~404 12-1N5401000021 RECTIFIER DIODE 1N5401 3A 100V
U1 16-TA8216H00021 IC (TOSHIBA) TA8216H
U2 16-NJM4558L0021 IC (NJRC) NJM4558L
U3 16-BA5417000021 IC (ROHM) BA5417
POWER PCB ASSY
