17
MC-DX33
REF.NO PARTS NO. DESCRIPTION REMARKS
05-DX33S0200000 PCBA-TUNER
48-02DX33B00220 TUNER PCB 94HB 88.5x92x1.6mm
CL2 38-013100050120 AXIAL INDUCTOR 10UH +-10% 350mA EC-24
CF201 31-028107001120 CERAMIC FILTER LT10.7MSC10-A(3PIN)(RED)
CF203 31-026450010110 CERAMIC FILTER (MURATA) SFU450B
CF204 31-028107001120 CERAMIC FILTER LT10.7MSC10-A(3PIN)(RED)
CF205 31-038107020120 DISCRIMINATOR FILTER JT10.7MG46-A (2PIN)
CF206 31-046456000220 RESONATOR ZTB456F15
CN201 44-555260052620 2P COAXIAL CABLE L=60mm TML(2)x2 AA
CN202,205,206 43-012200120120 WAFER 2mm 2P 180C
CN207 31-028107001020 CERAMIC FILTER LT10.7MJC10-A(3PIN)(RED)
CN512 43-022150210120 WAFER 10P 1.5mm 90C
C281 12-1N4148000021 DIODE 1N4148
D201,D202 12-1N41480000P1 SMD DIODE 1N4148 (1206)
IC202 16-LA1832000021 IC (SANYO) LA1832L-E (DIP)
IC203 16-LC7213100021 IC (SANYO) LC72131
IC300 16-BU1924F00021 IC (ROHM) BU1924F
L205,L1,R241 38-014100050120 AXIAL INDUCTOR 100UH +-10% 275mA EC-36
Q202,203,260 11-KTC9014S0025 SMD TRANSISTORS KTC9014S-C (KEC)
Q204 11-9015C0000021 PNP TRANSISTORS 9015C
Q205 11-9018G0000021 TRANSISTORS 9018G
Q208 16-LM78L0600021 IC (LIBERAL) LM78L06
T203 40-02A049004020 I.F.T 7mm A049 (YELLOW)
T204 40-023120000020 I.F.T 7mm 312A (BLACK)
T206 40-02660R002020 I.F.T 7mm 660R (RED)
SVC202 27-501602202020 TRIMMER 20PF 6mm (RED)
VD203 12-SVC321SPA021 VARACTOR DIODE (SANYO) SVC321SPA
VD204 12-SVC321SPA021 VARACTOR DIODE (SANYO) SVC321SPA
X201 31-017450002010 CRYSTAL 4.500MHz HC-49/US
X202 31-017433202120 CRYSTAL 4.332MHZ HC-49/US +-20PPM
ZD204 12-011390321625 SMD ZENER DIODE PDZ3.9B (934054849115)
TUNER PCB ASSY
