19
MC-DX33
REF.NO PARTS NO. DESCRIPTION REMARKS
05-DX33S0400000 PCBA-DIS "MCDX333S" EUR
48-04DX33B00220 DISPLAY PCB 84HB 147.5x89.5x1.6mm
CN1 43-022200120120 WAFER 2mm 2P 90C
CN2 43-022200120120 WAFER 2mm 2P 90C
CN8 43-022100212221 SMD F.F.C WAFER 1mm 12P 90C W/TOP LOCK
CN6,9 43-022150210120 WAFER 10P 1.5mm 90C
D102,A2,DE101,DE102 12-1N41480000P1 SMD DIODE 1N4148 (1206)
IC101 16-GY6550000021 MCU GY655 GENNY (80PIN QFP80)
LCD 13-05DX33B00020 LCD DISPLAY SDH-DA1744-TN-1 W/RDS
LED1,LED2 13-011200121020 LED LAMP 2x4mm (WHITE) LF244W3CJ-1A/01/P
LED3,LED4,LED5,LED6 13-011206022020 LED LAMP 2x4mm (BLUE)LF243B2CJ-2C-01
Q103 11-KTC9015S0025 SMD TRANSISTORS KTC9015S-C (KEC)
SW1,2,3,4,5,6,7,8,9,10,11,12 41-150010050020 TACT SWITCH 6x6mm 5mm (250g+-20g)4LEGS
XT101 31-018100002120 CRYSTAL 10MHz 49/US
XT102 31-015320003310 CRYSTAL 32.768KHZ (3x8mm)+-20PPM
ZD100 12-011360320825 SMD ZENER DIODE +-5% 3.6V 1/2W (LL34)
ZD101 12-011220320125 ZENER DIODE +-5% 2.2V 1/2W (T=52mm)
DISPLAY PCB ASSY
