21
MC-DX33
REF.NO PARTS NO. DESCRIPTION REMARKS
05-DX33S0800000 RCA/D-S JACK PCBA
48-08DX33B00220 RCA JACK PCB 94HB 88x30x1.6mm
CN801 43-462103003321 D-S TERMINAL #DSW-31 R1
CN802 43-012150160320 WAFER 1.5mm 6P 180C (DA23 & SAMSUNG CD)
CN803 44-316315054320 4P WIRE L=150mm HSG(2.5)x1 (UL1007#22)
L801,802,803,804 38-103100050320 CHOKE COIL 10UH +-10% D6x8mm 1A
RCA JACK PCB ASSY
REF.NO PARTS NO. DESCRIPTION REMARKS
LED PCB ASS'Y
48-16DX33B00220 LED PCB 94HB 31x14x1.6mm
D001 12-1N4148000021 DIODE 1N4148
D002 13-011309022020 LED LAMP 3mm(ORANGE/BLUE)LA309A2B2MA-C1
LED PCB ASSY
REF.NO PARTS NO. DESCRIPTION REMARKS
05-DX33B0900000 HP PCBA "BLK"
48-09DX33B00220 HP JACK PCB 94HB18.5x51.6x1.6mm
CN501A 44-565328053621 3P SHIELD WIRE L=280mm HSG+TML(2) (GREY)
CN507 44-535310057720 7P RAINBOW WIRE 100mm HSG+TML(2) AA
J001 43-431360002020 PHONE JACK D3.6mm TC38-060-01 BLK RING
J002 43-431360003020 PHONE JACK 3.6mm TC38-063-05-01 BLK RING
L401,402 38-013100050120 AXIAL INDUCTOR 10UH +-10% 350mA EC-24
L403 32-031351600025 FERRITE BEAD 3.5x6x0.8TB (TAPING)
AUX PCB ASSY
REF.NO PARTS NO. DESCRIPTION REMARKS
05-DX33S1900000 PCBA-VOL "MCDX33S" EUR
48-19DX33B00220 VOLUME PCB 94HB 84x11.5x1.6mm
CN4 44-535250052620 2P RAINBOW WIRE 50mm TML/90C+HSG(2)
SW13,14 41-150010050020 TACT SWITCH 6x6mm 5mm (250g+-20g)4LEGS
VOL PCB ASSY
