23
MC-DX33
REF.NO PARTS NO. DESCRIPTION REMARKS
05-DX33S0300000 PCBA-STANDBY
48-03DX33B00120 STANDBY PCB 94V0 60x80x1.6mm
RL301 46-50MC23000000 RELAY ME-7-009 HL(MASSUSE) 9V 10A 6.75V
CN301 43-012200130120 WAFER 2mm 3P 180C
FU1 46-074100300020 SUBMINIATURE FUSE D8.5xH8mm 100mA/250V
Q302 11-9014C0000021 NPN TRANSISTORS 9014C
Q303 16-LM78L0500121 IC (LIBERAL) LM78L05 (933510720676)
T301 18-205DX0150190 TRANSFORMER EI28 230V HF-V28A58
D309,310,311,312 12-1N4001000021 RECTIFIER DIODE 1N4001 1A 50V
STANDBY PCB ASSY
REF.NO PARTS NO. DESCRIPTION REMARKS
05-DX33S2700000 SENSOR PCBA
48-27DX33B00220 SENSOR PCB 94HB 30.5x11.7x1.6mm
17-05FM60380012 OPTIC SENSER (OPTO..) FM-6038TM2-5AN
CN11 44-335250053620 3P RAINBOW WIRE 50mm HSG(2)x1 UL1007#28
SENSOR PCB ASSY
REF.NO PARTS NO. DESCRIPTION REMARKS
05-DX33S1300000 PCBA-RC "MCDX33S"
48-13DX33B00320 REMOTE PCB FR4 123.5x42.6x1.6mm
IC1 16-PT2221000021 IC (ANGUS) PT2221-001
LED1 13-021300020020 INFRARED LED 3mm
Q1 11-MMBT39040221 SMD TRANSISTORS MMBT3904 SOT23
X1 31-046455000120 RESONATOR S455E
REMOTE CONTROL PCB ASSY
