9
MC-DX33
EXPLODED VIEW PARTS LIST
REF.NO PARTS NO. DESCRIPTION REMARK
1-87 66-120230160121 MACHINE SCREW MS/BH 3X6MM (BLK)
1-88 66-120240212121 MACHINE SCREW MS/BH 4x12MM (BLK)
1-89 66-140230210321 SELF-TAPPING SCREW TA/BH 3X10MM
1-90 66-140230212121 SELF-TAPPING SCREW TA/BH 3X12MM (BLK)
1-91 66-140230214121 SELF-TAPPING SCREW TA/BH 3X14MM (BLK)
1-92 66-120330160121 MACHINE SCREW MS/BH 3X6mm (BLK)
66-120330160321 MACHINE SCREW MS/BH 3X6mm (SLV)
1-93 66-141430214121 SCREW TA/BWH 4X14MM(HEAD 10MM) (BLK)
1-94 66-150230180123 HARDEN SCREW BTTB 3X8MM AB (BLK)
1-95 66-120526210321 MACHINE SCREW MS/KH 2.6X10mm (H:5mm)
1-96 66-140220150121 SELF-TAPPING SCREW TA/BH 2X5MM (BLK)
1-97 66-140226212311 SELF-TAPPING SCREW TA/BH 2.6X12MM (BLK)
66-140226212321 SELF-TAPPING SCREW TA/BH 2.6x12mm (SLV)
1-98 66-140230180321 SELF-TAPPING SCREW TA/BH 3X8MM
1-99 66-140330180321 SELF-TAPPING SCREW TA/PH 3X8MM
1-100 66-140330210321 SELF-TAPPING SCREW TA/PH 3X10MM
1-101 66-140330212321 SELF-TAPPING SCREW TA/PH 3X12MM
1-102 66-140330212121 SELF-TAPPING SCREW TA/PH 3X12MM (BLK)
66-140330214321 SELF-TAPPING SCREW TA/PH 3X13MM (SLV)
1-103 66-140526180311 SELF-TAPPING SCREW TA/KH 2.6X8MM
1-104 66-140526180321 SELF-TAPPING SCREW TA/KH 2.6X8MM (4KA BLK)
66-140226180321 SELF-TAPPING SCREW TA/BH 2.6x8mm (4KA SLV)
1-105 66-140523212121 SELF-TAPPING SCREW TA/KH 3X12MM (BLK)
66-140530212321 SELF-TAPPING SCREW TA/KH 3X12MM (SLV)
1-106 66-150530210121 SELF-TAPPING SCREW TB/KH 3X10MM (BLK)
66-150530210321 SELF-TAPPING SCREW TB/KH 3X10MM (SLV)
1-107 57-08DX01500020 CD DOOR PVC PLATE
1-108 66-140230210121 SELF-TAPPING SCREW TA/BH 3X10MM(BLK)
1-109 SWITCH PCB 2 ASSY CLOSE.................................... Included in REF. NO. 1-38 PCBA-CD,
Refer to page 12/14/15
1-110 SWITCH PCB 1 ASSY OPEN...................................... Included in REF. NO. 1-38 PCBA-CD,
Refer to page 12/14/15
1-111 LED PCB ASSY........................................................... Refer to page 20/21
1-112 05-DX33S0300000 PCBA-STANDBY
