Teac PD-H500C - Page 14

14
SERVICE MANUAL
CD MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A08792900 CDMAINPCBASS'Y
9A08790600 CDMAINPCB
9A05961500 PLATE,EARTH
9A05333500 HEATSINK
9A05328200 HOLDER,FUSE
9A08038100 RING,FERRITE
BD01 9A07050600 BEAD,CORE
C208£ 9A06764800 C,ELECT100UF/50V
C209£ 9A05976300 C,ELECT2200UF/35V
C213,214£ 9A06226700 C,ELECT1000UF/25V
C223£ 9A06764900 C,ELECT100UF/35V
CN01 9A08220300 WAFER,CARDCABLE
CN02 9A05329700 WAFER,MOLEX53014‑0610
CN03 9A05356400 WAFER,MOLEX53014‑0510
CN04 9A08789600 WAFER,CARDCABLE
CN05 9A08789500 WAFER,C.CABLE
CN06 9A05331000 WAFER,MOLEX53014‑1210
CN08 9A06674400 WAFER
CN09 9A05967800 WAFER
D102,103£ 9A05194600 DIODE,1N4003SRT
D104£ 9A05194700 DIODE,1N4003ST
D105£ 9A06765100 DIODE,ZENERMTZJ27BT
D106 9A06236200 DIODE,ZENERMTZJ6.2BT
D107‑111 9A01390500 DIODE,1N4148MT
D112 9A05194600 DIODE,1N4003SRT
D115 9A06236200 DIODE,ZENERMTZJ6.2BT
D504‑509£ 9A05194600 DIODE,1N4003SRT
IC01 9A08788500 IC,TA2150FN
IC02 9A08788700 IC,TC9462F
IC03 9A08788400 IC,TA2092N
IC04 9A08788600 IC,TA7291S
IC05 9A06786000 IC,TMP87PM78F
IC06 9A07263800 IC,SM5841AP
IC07 9A07263700 IC,BVIPCM69P
IC10 9A07343300 IC,NJM2068MD‑TE1
IC11£ 9A08788200 IC,NJM7809FA
IC12£ 9A08788300 IC,NJM7909FA
IC14,15£ 9A05341500 IC,KA7805‑ABTU
IC21£ 9A08790800 IC,KA78R08
IC8,9 9A07343300 IC,NJM2068MD‑TE1
JK01 9A06242100 JACK,LINEINTERMINAL
JK02 9A06242200 JACK,BOARD
JK03,04 9A06239100 MODULE,OPTICAL
L102,103 9A07330400 COIL,AXAIL
L104 9A05356900 COIL,AXAIL10UHK
Q102,103 9A05197500 TR,KTD1302T
Q104 9A08791000 TR,KRA107M
Q105 9A08791100 TR,KRC107M
Q106 9A03745100 TR,KSA1175‑YTA
Q107 9A08791000 TR,KRA107M
CD MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
Q108 9A08791100 TR,KRC107M
Q111 9A05196700 TR,KSA916‑Y‑SHTA
Q112,113 9A05197400 TR,KTC3203YT
Q114 9A03745100 TR,KSA1175‑YTA
Q115 9A03745000 TR,KSC2785‑YTA
Q116 9A05895900 TR,KTA1266YT
SW01 9A06244100 SWITCH,SLIDE
T101£ 9A08792800 TRANS,POWER
X101 9A05193100 CRYSTAL
X102 9A05193000 CRYSTAL
CD SUB PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A08793000 CDSUBPCBASS'Y
9A08793400 CDSUBPCB
9A05961600 BRACKET,FLT
CN04 9A08789600 WAFER,CARDCABLE
CN05 9A08789500 WAFER,C.CABLE
D101 9A08147300 LED,REDSLR342VCTB7
FIP1 9A07313300 F.I.P.SVA08MS14
IC01 9A08563600 SENSOR,REMOCON
S101 9A06671200 SW,TACTEVQ21505R
S103‑108 9A06671200 SW,TACTEVQ21505R
