Teac PD-H500C - Parts List; Exploded View List; Included Accessories

13
SERVICE MANUAL
EXPLODED VIEW LIST
REF.NO. PARTSNO. DESCRIPTION REMARKS
1 9A07264600 ORNAMENT,CD KGX1A221XC11
2 9A07264300 DOOR,CD KGR1A152K17
3 9A06240500 WINDOW KGU1A154Y
4 9A06677600 SIDEBAR KKM1A062C11
5 9A08792700 PANEL,AL KKM4A054WC11
6 9A08792200 PANEL,MOLD KGW4A179M9K64
7 9A08792000 WINDOW,SENSOR KGU1A245A10
8 9A07301300 INDICATOR,POWER KGL2A120
9 9A07301200 KNOB,POWER KBT2A387ZK64
10 9A06314300 KNOB,TACT(OPEN/CLOSE) KBT1A385YK64
11 9A06239700 KNOB,TACT KBT1A410C13
12 9A06316000 KNOB,TACT KBT1A386WK64
13 9A05961600 BRACKET,FLT KMD1A209
14 9A07265400 SUPPORT,MECHA KMH1A086
15 9A06229100 MOUNT,PCB KHE1A023
16 9A06315500 FOOT KKL1A047ZK63
17 9A06229300 CUSHION,FOOT KHG1A039Z
18 9A07266100 CHASSIS,MAIN KUA2A137
19 9A06315900 TOPCABINET KKC3B077S21
20 9A08792600 PANEL,REAR KKF2A127KK59
21£ 9A01376900 BUSHING,ACCORD KHR129
22£ 9A08152100 POWERCORD,2.5A250V BJA2B043Z
23 9A08788100 CDMECHANISMASS'Y BJDWSL2130KCTB
┗9A08788800CDPICK‑UPASS'YHJDKCTB1H
24 9A07264800 SUPPORT KHG2A163
25 9A06241700 RUBBER,TRANS KHG1A143
26 9A05326800 RUBBER KHG1A024
27 9A06224200 BADGE,TEAC BGB1A047
32£ 9A08792800 TRANS,POWER KLT5M020ZE
33 9A08793000 CDSUBPCBASS'Y KOP11367B
34 9A08792900 CDMAINPCBASS'Y KOP11366BEUR
F101£ 9A06868100 FUSE KBA2C0315TLE
9A08038100 RING,FERRITE KLZ9W001Z
INCLUDED ACCESSORIES
REF.NO. PARTSNO. DESCRIPTION REMARKS
9A08524500 OWNER'SMNL,EUR KQX1A617Z
9A05935900 CORD,PIN KJS4M014Y
9A05936000 CORD,PIN KJS4N001Y
