9
SR-L230i
REF.NO TEAC PARTS NO. PARTS NO. DESCRIPTION REMARK
1-1 010-230B0300-R DUCT COVER <L> (COLOR:BLACK)
010-230W0300-R DUCT COVER <L> (COLOR:WHITE)
1-2 010-230B0400-R DUCT COVER <R> (COLOR:BLACK)
010-230W0400-R DUCT COVER <R> (COLOR:WHITE)
1-3 023-23010033-R SCREW
3X10MM BB BLACK HD
023-23010031-R SCREW 3X10MM BB NI HD
1-4 044-R230i051-R SPEAKER PAPER TUBE 18X 22X80MM
1-5 035-R230i102-R DUCT COVER L/R EVA SHEET
1-6 010-230i0100-R SPEAKER BOX L
1-7 010-230i0200-R SPEAKER BOX R
1-8 035-R230i012-R R/L SPEAKER EVA WASHER
1-9 099-39R230i1-R ABSORB COTTON A
1-10 061-230i0400-R SPEAKER 2.5" 4 OHM 5-8W
1-11 024-43008033-R SCREW 3X8MM PWA BLACK HD
EXPLODED VIEW-1
PARTS LIST
To Next Page
