Specifications Right hand chute
Sloping Swivel Chute Dual Chop
Model
8100 8100SC
8150
Number of crossbeaters 1 1
1
Chamber width 1.55 m
1.55 m 1.55 m
Side discharge height - barrier 1.55 m 2.38 m
2.38 m
Giraffe discharge height - max. N/A 3.66 m
3.66 m
Giraffe rotation angle N/A
280 degrees 280 degrees
Overall width (all chutes closed) 2.27 m 2.02 m
2.02 m
Overall width (side chute raised) 3.06 m N/A
N/A
Overall height - maximum 2.41 m 3.22 m
3.22 m
Overall height - minimum 2.41 m 2.54 m
2.54 m
Overall length (tailgate up) 4.19 m 4.19 m
4.19 m
Overall length (tailgate down) 5.42 m 5.42 m
5.42 m
Maximum round bale diameter 1.83 m 1.83 m
1.83 m
Maximum rectangular bale size
1.3m x 1.2m x 2.5m
Tyre size (standard tyres) 10.0/75 – 15.3 10.0/75 – 15.3 10.0/75 – 15.3
Wheel track (standard Tyres) 1.75 m 1.75 m
1.75
Weight 1880 Kg 1960 Kg
2168 Kg
Volume of clamp silage 2.5 m
3
2.5 m
3
N/A
Maximum hydraulic oil pressure
220 bar (3190 psi)
Maximum hydraulic oil flow
60 litres/minute (13.2 gal/min)
Minimum hydraulic oil flow 35 litres/minute (7.7 gal/min)
Maximum drawbar load 650 Kg 650 Kg 650 Kg
Minimum tractor size 45kW (60hp) 45kW (60hp) 45kW (60hp)
Sound power level 95 dbA 95 dbA 95 dbA
1.2 8100 / 8150 SPECIFICATIONS
