Specifications
Right hand chute Sloping swivel chute Dual Chop
Model 8500 8500
8555
Number of crossbeaters 1 1
1
Chamber width
1.7 m 1.7 m 1.7 m
Side discharge height - barrier 1.55 m 2.38 m 2.38 m
Giraffe discharge height - maximum
N/A
3.66 m 3.66 m
Giraffe rotation angle
N/A
280 degrees 280 degrees
Overall width (all chutes closed) 2.48 m 2.21 m 2.21 m
Overall width (side chute raised) 3.47 m N/A N/A
Overall height - maximum 2.77 m 3.51 m 3.51 m
Overall height - minimum 2.57 m 2.83 m 2.83 m
Overall length (tailgate up) 4.19 m 4.19 m 4.19 m
Overall length (tailgate down) 5.42 m 5.42 m 5.42 m
Max Round bale diameter 2.00 m 2.00 m
2.00 m
Maximum rectangular bale size 1.3m x 1.2m x 2.5m 1.3m x 1.2m x 2.5m
1.3m x 1.2m x 2.5m
Tyre size (standard tyres) 12.5/80 – 15.3 12.5/80 – 15.3 12.5/80 – 15.3
Wheel track (standard tyres) 1.90 m 1.90 m 1.90 m
Weight 2080 Kg 2080 Kg
2,450 Kg
Volume of clamp silage 4.5 m
3
4.5 m
3
N/A
Maximum hydraulic oil pressure 220 bar (3190 psi) 220 bar (3190 psi)
220 Bar (3190 psi)
Maximum hydraulic oil flow 60 l/min (13.2 gal/min) 60 l/min (13.2 gal/min) 60 l/min (13.2 gal/min)
Minimum hydraulic oil flow 35 l/min (7.7gal/min) 35 l/min (7.7 gal/min)
35 litres/min (7.7 gal/min)
Maximum drawbar load 650 Kg 650 Kg
600 Kg
Minimum tractor size 60kW (80hp) 60kW (80hp)
66kW (90hp)
Sound power level 95 dbA 95 dbA 95 dbA
1.3 8500 / 8555 SPECIFICATIONS
9
