Specifications
Right Hand Chute
Sloping Swivel
Chute
Right Hand Chute
Sloping Swivel
Chute
Model 9500
9500SC
1010 1010SC
Number of crossbeaters
2 2 2 2
Chamber width
1.7 m 1.7 m 1.7 m 1.7 m
Side discharge height - barrier 2.00 m 2.45 m
2.00 m 2.45 m
Giraffe discharge height - maxi-
mum
N/A
3.00 m
N/A 3.00 m
Giraffe rotation angle
N/A
280 degrees
N/A 280 degrees
Overall width (all chutes closed)
2.48 m
2.20 m
2.57 m 2.39 m
Overall width (side chute raised) 3.47 m
N/A 3.56 m N/A
Overall height - maximum
2.93 m 3.54 m 2.96 m 3.61 m
Overall height - minimum
2.93 m 2.91 m 2.96 m 2.95 m
Overall length (tailgate up) 5.17m 5.17m
6.19 m 6.19 m
Overall length (tailgate down) 6.34m 6.34m
7.32 m 7.32 m
Max Round bale diameter 2.00 m 2.00 m
2.00 m 2.00 m
Maximum rectangular bale size 1.5m x 1.2m x 2.5m 1.5m x 1.2m x 2.5m
1.3m x 1.2m x 2.5m 1.3m x 1.2m x 2.5m
Tyre size (standard tyres) 305/55 R22.5 305/55 R22.5
385/55 R22.5 385/55 R22.5
Wheel track (standard tyres) 1.9 m
1.9 m 2.0 m 2.0 m
Weight 3080 Kg 3160 Kg
3510 Kg 3590 Kg
Volume of clamp silage 8 m
3
8 m
3
10.0 m
3
10.0 m
3
Maximum hydraulic oil pressure 220 bar (3190 psi) 220 bar (3190 psi)
220 Bar (3190 psi) 220 Bar (3190 psi)
Maximum hydraulic oil flow
60 litres/min (13.2
gallons/min)
60 litres/min (13.2
gallons/min)
60 litres/min (13.2
gallons/min)
60 litres/min (13.2
gallons/min)
Minimum hydraulic oil flow
45 litres/min (9.9
gallons/min)
45 litres/min (9.9
gallons/min)
45 litres/min (9.9
gallons/min)
45 litres/min (9.9
gallons/min)
Maximum drawbar load 600 Kg 600 Kg
600 Kg 600 Kg
Minimum tractor Size 65kW (87hp) 65kW (87hp)
66kW (90hp) 66kW (90hp)
Sound power level 86 dbA 86 dbA
86 dbA 86 dbA
1.4 9500 / 1010 SPECIFICATIONS
