25
10.6 SOLENOID VALVE PARTS
INDEPENDENT BED SPEED CONTROL SLICE
Ref Description Part No. RH SC TC/DC
A Inlet Cover HYD5098 1 1 1
B Double acting slice – spring return HYD5192 3 4 6
C Relief valve assembly HYD5070 1 1 1
D Flow control slice HYD5314 1 1 1
E Outlet Cover HYD5315 1 1 1
Complete valve seal kit -- HYD5172 HYD5173 HYD5174
Valve slice seal kit HYD5316 5 6 9
Flow control valve seal kit HYD5317 1 1 1
10.7 SOLENOID VALVE PARTS
COMBINED SPEED CONTROL/FORWARD SLICE
Ref Description Part No. RH SC DC TC
A Cover (Bed control end) HYD5406 1 1 1 1
B Relief valve assembly HYD5407 1 1 1 1
C Double acting slice – spring return HYD5192 2 3 4 5
D Flow control slice HYD5404 1 1 1 1
E Bed reverse slice HYD5405 1 1 1 1
F Outlet Cover HYD5315 1 1 1 1
G Flow dividing slice HYD5198 1 1 1 1
Complete valve seal kit HYD5174 1 1 1 1
Valve slice seal kit HYD5316 2 3 4 5
Reverse slice seal kit HYD5408 1 1 1 1
Flow control slice seal kit HYD5409 1 1 1 1
