Ref. Description Part No. Qty. Associated Components Part No. Qty.
11 Outer Lower Panel SC3613 2 Cup Square Bolt M10 x 25 FAS9262P 4
Setscrew M10 x 20 FAS2654P 4
Plain Washer M10 FAS2344P 12
Locknut M10 FAS2333 8
12 Tailgate Ram - Metric CYL1135 2
13 Axle Pivot Pin SC3296 2 Spring Tension Pin 8 x 40 FAS4131S 4
14 Wheel 10/75 x 15.3 - 6 Stud WE1105 2 Wheel Rim - 6 Stud WE1124 2
Inner Tube WE1103 2
Tyre WE1102 2
15 Axle 1900mm SC4618 1 Bolt M16 x 80 FAS9711P 4
Locknut M16 FAS2335 4
16 Chassis SC4600 1 Plastic Round Insert SC4215 4
Bolt M20 x 65 FAS9733P 4
Locknut M20 FAS2336 4
Setscrew M12 x 40 FAS2680P 2
Plain Washer M12 FAS2345P 4
Locknut M12 FAS2334 2
DECALS
Description Part No. Qty. Description Part No. Qty.
Teagle DL1320 3 Warning - Read Instruction Book DL1006 1
Teagle DL1220 1 Swish LH DL1328 1
Bed Chain Speed Indicator DL1081 1 Swish RH DL1329 1
Tomahawk DL1321 2 8500 DL1324 2
Serial Number Plate - T8500 DL2054 1 8550 DL1325 2
Serial Number Plate - T8550 DL2055 1 Pop Rivets FAS9069
Dual Chop DL1330 2 Hydraulic Oil Pressure DL1099 1
Fingers Being Severed DL1033 2 Oil Flow Rate & Direction DL1109 1
Do Not Permit Riders DL1036 1 Thrown Objects DL1039 1
Tighten Wheel Nuts DL1209 2 Crushed Body DL1041 2
Blockage Removal Tool DL1070 1 Gearbox Speed DL1073 1
PTO Speed 540 RPM DL1012 1
To Next Page
