Switches 1 - 5 are used to select the time increment MULTIPLIER as follows (same function
for both DSW1 & DSW2):
Switch 1 2 3 4 5 MULTIPLIER
1 0 0 0 0 1
0 1 0 0 0 2
1 1 0 0 0 3
0 0 1 0 0 4
1 0 1 0 0 5
0 1 1 0 0 6
1 1 1 0 0 7
0 0 0 1 0 8
1 0 0 1 0 9
0 1 0 1 0 10
1 1 0 1 0 11
0 0 1 1 0 12
1 0 1 1 0 13
0 1 1 1 0 14
1 1 1 1 0 15
0 0 0 0 1 16
1 0 0 0 1 17
0 1 0 0 1 18
1 1 0 0 1 19
0 0 1 0 1 20
1 0 1 0 1 21
0 1 1 0 1 22
1 1 1 0 1 23
0 0 0 1 1 24
1 0 0 1 1 25
0 1 0 1 1 26
1 1 0 1 1 27
0 0 1 1 1 28
1 0 1 1 1 29
0 1 1 1 1 30
Example : DELAY TIME = 20 seconds, PUMP ON TIME = 10 seconds
Switch 1 2 3 4 5 6 7 8 Time Setting
DSW1 0 1 0 1 0 0 0 0 10 x 2 sec
DSW2 1 0 0 0 0 0 1 0 1 x 10 sec
NOTE: DSW1 & DSW2 must be set prior to power-on. Changes to the switch settings
whist the Controller is powered will not be recognised.
If an invalid setting has been made eg. out of range multiplier, the error will be signalled
by a flashing ' 0' on the CYCLES display.
