TECALEMIT TC100D2 - OPTION DESCRIPTIONS; OPTION 0: OP1 Pulse Interval & DOSAGES Disable; OPTION 1: Pump On Time Termination by IP1; OPTION 2: IP2 as Remote Test Input

TC100D2-V6 0 MANUAL Apr 08 A4 (reflowed).docx Page 5 of 6
APPLICATION: Single Line Progressive
OP1 - Pump
IP1 - Cycle switch
IP2 - Low Level or Remote Test switch
Single Line Injector with automatic vent valve
OP1 - Pump
IP1 - Pressure switch
IP2 - Low Level or Remote Test switch
Dual Line with automatic reversing valve
OP1 - Pump
IP1 - Cycle switch
IP2 - Low Level or Remote Test switch
Single Line Injector with electric vent valve
OP1 - Pump
OP2 - Electric vent valve
IP1 - Pressure switch
IP2 - Low Level or Remote Test switch
OPTION 0 - (DSW3 switch 5 ON)
This option modifies the base program to allow OP1 pulse interval (pulsing option selected via
DSW2) to be set between 1 - 15 sec using switches 1 - 4. Selecting OPTION 0 disables the
DOSAGES feature.
OPTION 1 - (DSW3 switch 6 ON)
This option modifies the base program so that the Pump On Time will terminate on IP1
activation or when the number of IP1 activations (doses) = the number preset on DSW3 (n = 1-
15).
OPTION 2 - (DSW3 switch 7 ON)
This option modifies the base program to use a Remote Test switch input in place of the Low
Level switch input. The Remote Test switch connected to IP2 mimics the TEST switch on the
front panel.
OPTION 3 - (DSW3 switch 8 ON)
This option modifies the base program to cancel the FAULT alarm function ie. Ignore IP1.
