Operator's guide
16. Retighten the top panel
screws using a screwdriver
17. Refit the lock housing
and lock pin.
18. After reversing the door,
it is important to check that the
sealing strip provides a tight
seal all the way round.
If it does not, carefully heat the
strip all the way round using
a hair dryer. Then ease the strip
outwards slightly so that it
forms a tight seal against the
cabinet. Be careful not to heat
the strip so much that it melts!
Reversing the door for appliance with 2 doors.
●●Dismount the middle hing pin
and bushing.
Dismount the door●●
Cover for hinge hole is dismounted●●
an remounted in opposite site.
Adjustment of the door.
Mounting of lock for appliance
with 1 door. (Optional extra.)
Mounting of lock
for appliance
with 2 doors.
(Optional extra.)
VKG 581:
SHOULD THE HINGE
REVERSING THE DOOR
CVKS pag. 22
